Summary of Contents for Frey PERIMETER AP-300
- Page 1 QUICK SUPPORT GUIDE PERIMETER AP-300 How to: - perform exam - setup the most used testing strategy - print result and understand the printout layout 2018 www.freymedical.eu...
- Page 2 THERE ARE TWO WAYS TO PERFORM AN EXAM: I. STANDARD ACCESS Select 'New exam' from the Main Menu. Set the required parameters of an exam (the example below shows the most used settings: Central 30-2 field, Fast Threshold strategy and ...
- Page 3 After clicking 'OK' the exam is being prepared. When the test screen appears, please position a patient that his/her pupil is more or less in the centre of the camera window (no need to position it very precisely!). You should advice the patient to look into the fixation point in the perimeter bowl.
- Page 4 II. QUICK ACCESS (via SIMPLE MENU) The 'Simple Menu' is a concept which minimizes the time required to start an exam. You can define your most used test or tests and they will be attached to the buttons on the main screen.
- Page 5 Press for example the first button. The configuration screen will appear: Please define parameters according to your needs (this example sets the most used standard: Central 30-2 field and Fast Threshold strategy). You can name the exam as you want (the 'User exam name' field) or leave it black (it will have a default name).
-
Page 6: Printing Results
PRINTING RESULTS How to define your required print format? Let's assume you need the most used 'Standard HFA' format. 1. Please go to the 'Service Menu": 2. Then go to the 'Print layout' tab: 3. From the 'Default printout' combo box select 'Standard HFA' and click the 'Save' button. - Page 7 The most used printout format is called 'Standard INFORMATION ABOUT PRINTOUTS HFA' and is compatible with standard introduce by Zeiss Humphrey in their HFA perimeters line. TEST PARAMETERS GREY PATTERN dB MAP (IN DECIBELS) TOTAL DEVIATION PATTERN DEVIATION TOTAL GLOBAL DEVIATION INDEXES PROBABILITY...
-
Page 8: Your Distributor
YOUR DISTRIBUTOR CONTACT DETAILS: CONTACT E-MAILS: FREY S.J. Technical support: tech@frey.pl ul. Ceramiczna 24a Marketing: contact@freymedical.eu 05-502 Piaseczno, Gołków Office: frey@freymedical.eu www.freymedical.eu...
