OPERATION / HEADSET (Cont'd)
CALL BACK (LAST INCOMING)
Press the Volume (+) AND Volume (-) Buttons until a beep is heard. Redialing the last INCOMING call
should begin automatically.
NOTE: Your Bluetooth ® phone must support last incoming call capability to use this feature. Consult your
phone's user guide for information specific to your phone.
HANDS-FREE CAR KIT
Install the Docking Station into an available cigarette lighter socket or 12V DC power outlet in the vehicle.
Place the headset into the dock MIC first (nose first).
NOTE: Ear hook may need to be rotated out of the way to allow a good fit into the dock. Make sure the
headset sits flat in the dock and makes contact with the row of tiny pins. Your CBH Bluetooth
function as a hands-free car kit when the headset docked. Your hands-free conversations will utilize the MIC
and SPEAKER built into the dock.
POWER ON:
Press the Power Button. The GREEN indicator will turn on indicating the dock has power.
HEADSET CHARGE:
Your CBH Bluetooth ® Headset battery will re-charge when docked into the base.
VOLUME:
During conversation, use the volume dial on the right side of the dock to increase or decrease the speaker
volume.
OPERATION:
You can perform the following functions accessing the power button on the CBH Headset while it is docked in
the base:
• •
Call Answer Call End
• •
Voice Dial Last number redial
LED CHART
LED/COLOR
Blue LED blinks every 5 seconds
Blue LED blinks every 1 second
Blue LED blinks quickly
Red LED Solid
Red LED Off
LIMITED WARRANTY
Scosche Industries Inc. warrants this product to be free from defects in material and workmanship for a period of 90 days from
purchase. This Scosche product is sold with the understanding that the purchaser has independently determined the suitability
of this product. This warranty is offered to the original purchaser of the product only. This warranty does not cover the product if
physically damaged, subjected to negligence or misuse, abuse, alteration, accident, or an act of God. This warranty does not
apply to product which has been water or physically damaged, damaged by accident or which has been misused,
disassembled or altered.
The original dated sales slip or proof of purchase will establish warranty eligibility. If the product should prove defective within
the warranty period, return the product with proof of purchase to Scosche Industries Inc. Scosche, at it's option, will replace or
repair the product free of charge and return the product postage paid.
In no event shall Scosche Industries, Inc. be responsible for claims beyond the replacement value of the defective product, or in
any way be liable or responsible for consequential or incidental damages.
No express warranties and no implied warranties, whether for fitness or any particular use, or otherwise, except as set forth
above (which is made expressly in lieu of all other warranties) shall apply to products sold by Scosche. Scosche Industries
cannot be held responsible for discrepancies/inconsistencies that may occur due to automotive manufacturing changes or
options.
This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: 1) This device may not cause
interference, and (2) this device must accept any interference that may be received, including interference that may cause undesired
operation. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modification to this equipment.
Such modification could void the user's authority to operate the equipment.
(Headset placed in vehicle dock)
®
•
Call Reject
•
Call Swap
STATUS
Connected with mobile phone
(Standby)
Connected with mobile phone
(Conversion/Call)
Pairing mode
Battery Charge
Charging Complete
4
CELLULAR BLUETOOTH
Congratulations on your purchase of CBH Cellular Bluetooth
latest Bluetooth
please read this manual carefully.
FEATURES:
• Cigarette Lighter Dock/Charger Station
• Rechargeable Battery with up to 8
hours talk time and 210 hours stand-by
time.
Headset will
• Call Functions: Send, End, Reject,
Redial, and Voice dial
• Seamless switching between headset
and phone
HEADSET DIAGRAM:
1. Switch ON/OFF Headset, Answer Call,
Reject Call (Multi-Function Button)
2. Volume Up, pair the headset with
Bluetooth
3. Volume Down
4. Ear Hook (2 sizes included)
CIGARETTE LIGHTER DOCK/CHARGER STATION:
10. Contact Pins for Headset
11. Power ON/OFF Switch
12. Volume Dial
This product may not be compatible with all Bluetooth
or may not include send/end control functions, volume adjustment and voice dialing. Please consult your
Bluetooth ® enabled cell phone operation manual for specific features and instructions.
© 2006 SCOSCHE INDUSTRIES, INC.
OXNARD, CA 93033
300CBH 3/06 Rev A
HANDS FREE KIT
®
® technology for seamless integration with most Bluetooth
SYSTEM OVERVIEW
® Device
5
1
4
3
2
8
7
10
11
16
12
13
14
® features on all Bluetooth
If you have any further questions, all our TOLL-FREE number:
TECHNICAL HELP line 1-800-621-3695 x3
CBH
®
HEADSET WITH
Hands Free kit. This system incorporates the
® enable cell phones. Before using,
•
Microphone mute
•
3-Way calling (on supported phones)
•
Call-back last incoming call (on
supported phones)
•
USB charging cable included
•
2 ear hooks included / works with LEFT
or RIGHT ear (Universal)
5. LED Indicator (RED/BLUE)
6. Headset Speaker
7. Microphone
8. Mini USB Port (charge the battery)
9. Contact Pins for Dock Station
6
9
13. MIC
14. Power LED
15. Built-In-Speaker
16. Lighter Probe
15
