Summary of Contents for Curv CT12060
- Page 1 Curv-infrared.com The Smarter Way To Heat Your Home Installation & Operating Instructions For Cürv, Flat, Towel Rail and Mirror Infrared Heaters...
-
Page 2: Safety Precautions
Safety Precautions Important Notice To Purchaser Before installing this heater, the user should determine the suitability of the heater and its intended use. Cürv360 Limited shall not be liable for any direct, indirect special, incidental or consequential damages resulting from improper product use. Waste electrical products should not be disposed of with household waste. - Page 3 IP Protection IP44 - Cürv Towel Rails IP44 - Cürv Mirrors IP50 - Cürv & Flat Heaters Only the Cürv Towel Rails and Cürv Mirrors are rated to IP44 enabling them to be located within a splash zones in a bathroom (Zone 2). However, installation in potentially wet or humid rooms such as bathrooms must be carried out by a suitably qualified installer and comply with local electrical safety requirements.
- Page 4 Caution All Installations should only be carried out by suitably qualified person or competent persons. If the Cürv Infrared Heater is being hard wired (so the plug is removed), the electrical installation should only be carried out by suitably qualified personnel. Wiring to this appliance must be connected in accordance with the relevant national electrical safety standards.
- Page 5 Cleaning Before attempting to clean the heater, unplug the heater or isolate the heater from the electrical supply and allow it to completely cool down. DO NOT immerse the Cürv Infrared heater in water. Clean the heater with a damp cloth. For mirror models and towel rails glass cleaner can be used.
- Page 6 Curv cannot be held responsible for the quality or consistency of your internet connection and faults should be addressed with your provider. This Limited Warranty does not guarantee that the use of the Curv Smart products will be uninterrupted or error free.
-
Page 7: Heater Controls
Heater Controls WIFI connection Flashing green when pairing or searching Solid green when paired Room Thermostat Connection Solid green when pairing to room stat Flashing green when communicating with room stat ON Switch Heat on with WIFI and Room stat functionality OFF Switch Heater Off... -
Page 8: Installation Guide
Installation Guide Our heaters can be installed horizontally or vertically to suit your requirements. We supply a fixing pack containing wall fixings, mini level, drill bit and fixing template. To install horizontally fix the bracket to the wall with the A pointing up. -
Page 9: Heater Installation
Heater Installation Step 1 Please remove transportation screws before installation. Place the bracket on the wall centrally where you wish to install the heater then mark the fixing holes or use the template provided. Step 2 Drill the holes with the drill bit supplied then use the correct wall fixings to secure the bracket to the wall: Fixings Step 3... - Page 10 Fixing Locations Please use these measurements below or the template provided, to install for your Cürv Towel Rail. ( ) mark the fixing points. 20mm 20mm Fig 1. 1200 x 600 - CT12060 Fig 2. 600 x 600 - CT6060...
- Page 11 Wireless Room Thermostat Pairing set (PAIR) Quick press thermostat On / Off Timer setting (PRG) Long press to start the timer mode Current time set (TIME) Select High (H), Medium (M) or Low (L) Increase Temperature heating mode. scroll left Long press to switch to Celsius Press and hold SET for 3 seconds for frost/holiday mode.
- Page 12 Installing Wireless Room Thermostat Install the Cürv Thermostat away from drafts, radiators, fireplaces, or direct sunlight or anything that would cause the temperature to be artificially high or low. Do not fix directly above the Cürv heater. Recommended installation height 1.5 metres when fixing cradle to the wall: To Pair the Wireless Room Thermostat Install 4 x AAA batteries in the room thermostat.
- Page 13 To Set Date and Time (Note. If you are using the Cürv Smart App the time and date will automatically be updated.) Press the until you reach the “TIME” option. Press Set. Use ‘+’ and ‘-’ to select the Day. Press Use ‘+’...
- Page 14 The Cürv App To Control your Heater with the Cürv App please search “Cürv” in the App store and download the Cürv Infrared App. Download the App. Click on Register. Enter your mobile phone number and press Get Code. You will receive a text with a verification code. Please enter the code and press next, then fill in you details and register.
- Page 15 Add A Heater 1. You then need to pair the App with your WI-FI network by pressing the Icon on the bottom menu bar. 2. Select your WI-FI SSID (router) then enter the password, then click ‘Connect’. 3. Press the button on your heater for 3 seconds until it flashes.
- Page 16 Create an area / room with 2 or more heaters From the main menu page press + (in the top right- hand corner). Give the group of heaters a name. You can also add a picture if you wish. Press Save. From your list of heaters in my devices select the heater you wish to move into the group swipe left to reveal...
- Page 17 To allow multiple users to control the heater Each user must create an account on their device. From the origional device that paired the heaters, go into the heater control screen and press in the top right-hand corner. Select share, this will display a QR code which can be scanned by the other device you wish to share the heater with.
- Page 18 Cürv Heater To program a heating scheldue Select the heater or group of heaters you wish to set up the schedule. Press (in the top right corner) and selecting timer from the drop-down menu. Cürv Heater Press the + to add a schedule. Cürv Heater Set your start time.
- Page 19 Heater Control Features To previous page. Cürv Heater Share heaters and program time schedules. ON / OFF Turns the heater on and off. TIMER Turns the heater in timer mode (if scheduled). C / F Switch temperature display between °C to °F. BOOST Press boost for a 30, 60 or 90 minute heating boost.
- Page 20 Curv360 Limited, Lakes Court, Newborough Road, Burton on Trent, DE13 9PD Manufactured in China curv-infrared.com...
