Arnott AS-2856 Manual

Rear air strut for lexus ls460 (sf40)
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Congratulations on your purchase of an Arnott
to offer a high quality product at the industry's most competitive pricing. Thank you for your confidence in us
Proper installation is essential to experience and appreciate the benefits of this system. Please take a moment
to review these installation instructions before you begin to install these components on your vehicle. The
removal and installation of air suspension products should only be performed by a fully qualified, ASE
It is equally important to be aware of all necessary safety measures while installing your new Air Suspension
System. This includes proper lifting and immobilizing of the vehicle and isolation of any stored energy to
WARNING: The air suspension system is under pressure (up to 10 bar, or 150 lbf/in). Verify pressure has been relieved
and disconnect power to the air suspension system prior to disassembly. Do not allow dirt or grease to enter the system.
Always wear standard hand, ear, and eye protection when servicing the air suspension system.
Arnott
is committed to the quality of its products. If you have a question or problem with any Arnott product,
®
please contact Arnott by calling 800-251-8993 during normal business hours or email techassistance@arnottinc.com.
(In the EU please call +31 (0)73 7850 580 or email info@arnotteurope.com)
1
AS-2856
REAR AIR STRUT
LEXUS LS460 (XF40)
air suspension product. We at Arnott Incorporated are proud
®
and our product.
Certified, professional.
prevent personal injury or property damage.
"Engineered to Ride, Built to Last
AS-2856
ARNOTT
"
®
REV 1
05/31/2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AS-2856 and is the answer not in the manual?

Questions and answers

Related Manuals for Arnott AS-2856

Summary of Contents for Arnott AS-2856

  • Page 1 Always wear standard hand, ear, and eye protection when servicing the air suspension system. Arnott is committed to the quality of its products. If you have a question or problem with any Arnott product, ® please contact Arnott by calling 800-251-8993 during normal business hours or email techassistance@arnottinc.com.

  • Page 2: General Information

    AS-2856 ARNOTT REAR AIR STRUT LEXUS LS460 (XF40) GENERAL INFORMATION: Reading this manual signifies your agreement to the terms of the general release, waiver of liability, and hold harmless agreement, the full text of which is available at www.arnottinc.com. •...
  • Page 3 AS-2856 ARNOTT REAR AIR STRUT LEXUS LS460 (XF40) LIFT UP THE REAR DECK PANEL TO EXPOSE THE TOP CAP . LOOSEN AND REMOVE THE THREE TOP CAP NUTS. (FIGURE 2) FIGURE 2 REMOVE THE TOP CAP . (FIGURE 3) FIGURE 3 ROTATE AND REMOVE THE TOP CAP SENSOR.
  • Page 4 AS-2856 ARNOTT REAR AIR STRUT LEXUS LS460 (XF40) LOOSEN AND REMOVE THE THREE TOP MOUNTING NUTS FROM THE SHOCK. (FIGURE 5, 6) FIGURE 6 FIGURE 5 REMOVE THE AIR LINE. TO DO THIS, PUSH THE TABS INWARD AND TWIST UNTIL THE CLIP ALIGNS WITH THE HOLES IN THE FITTING, ALLOWING THE AIR LINE TO BE REMOVED.
  • Page 5 AS-2856 ARNOTT REAR AIR STRUT LEXUS LS460 (XF40) LOOSEN AND REMOVE THE SWAY BAR END LINK NUT AND SEPERATE. (FIGURES 10, 11) FIGURE 11 FIGURE 10 LOOSEN AND REMOVE THE BOTTOM MOUNT NUT AND BOLT. (FIGURE 12) FIGURE 12 REMOVE THE SHOCK FROM THE VEHICLE. (FIGURE 13) FIGURE 13 REMOVAL COMPLETE.
  • Page 6 AS-2856 ARNOTT REAR AIR STRUT LEXUS LS460 (XF40) AIR STRUT INSTALLATION Tighten all nuts and bolts to manufacturer's specifications during the installation process. INSTALL THE NEW AIR SHOCK INTO THE VEHICLE WITH THE AIR FITTING POINTED TOWARDS THE WHEEL. (FIGURE 1)
  • Page 7 AS-2856 ARNOTT REAR AIR STRUT LEXUS LS460 (XF40) REINSTALL THE SWAY BAR END LINK NUT AND TIGHTEN TO MANUFACTURER'S SPECIFICATIONS. (FIGURE 13) FIGURE 13 INSTALL THE THE THREE TOP MOUNTING NUTS TO THE SHOCK AND TIGHTEN TO MANUFACTURER'S SPECIFICATIONS. (FIGURE 14) FIGURE 14 REINSTALL THE TOP CAP SENSOR.
  • Page 8 AS-2856 ARNOTT REAR AIR STRUT LEXUS LS460 (XF40) REINSTALL THE TOP CAP . INSTALL THE TOP CAP NUTS AND TIGHTEN TO MANUFACTURER'S SPECIFICATIONS. (FIGURE 16) FIGURE 16 REINSTALL THE AIR LINE. TO DO THIS, PUSH THE TABS INWARD AND TWIST UNTIL THE CLIP ALIGNS WITH THE HOLES IN THE FITTING, ALLOWING THE AIR LINE TO BE PROPERLY INSTALLED.
