Disassemble the Power Survivor according to
chapter "Seal Replacement" in the manual.
4
Silicon
Cone
Grease
Place the assembly tool over the bore-
hole with the cone-shaped taper on top.
Print. No. 8018461/1
2
--
Housing
screw
Prepare the spare parts and grease the
spool valve seals.
5
Press the spool valve by hand into
the borehole.
Assembly Instruction Spool Valve
Silicon Grease
Assembly
Spool valve
tool
6
Use the screw as an extension to
press the spool valve completely
into the borehole.
Power Survivor 40
3
Borehole
Silicon
Grease
Lightly grease the borehole before
inserting the spool valve.
7
The repair is complete when the spool
valve is entirely inside the housing.
