I. Learn about your camera
Network Interface
Specificaton:
720P Network IP Camera
Remote View by APP on smart phone
Built-in microphone & Speaker
Y03-720P
Fast Operation Guide
Wifi Antenna
Micro Card Slot
Infrared night vision
HD Camera
Infrared Sensor
Microphone
Power Port
IR-CUT
Infrared LED for night view
Motion Detection
Advertisement
Related Manuals for GLOBAL Export Import Y03-720P
Summary of Contents for GLOBAL Export Import Y03-720P
- Page 1 Y03-720P Fast Operation Guide I. Learn about your camera Wifi Antenna Infrared night vision HD Camera Infrared Sensor Microphone Power Port Micro Card Slot Network Interface Specificaton: 720P Network IP Camera IR-CUT Remote View by APP on smart phone Infrared LED for night view Built-in microphone &...
-
Page 2: Add Camera
Technical Data: Min. Illumination: 0.1 LUX / F1.2 Core Chipset: GM8135S Video Compression: H.264/ MJPEG Operating system: Linux Video Streaming: TCP UDP Image Sensor: 1.0M pixels HD CMOS Audio Compression: G711A Resolution: 1280*720 Protocol: TCP/IP, ICMP, UDP, RTSP, DHCP Frame Rate: 25fps~30fps Lens: 3.6mm Wireless Lan: IEEE802.11b/g/n IR LEDs: 11pcs... - Page 3 2. Process of adding new devices Device needs to be back to initialized status by pressing the “reset” button for 5 seconds when adding new devices. Two ways for adding device: one is via WiFi, the other is via wire. WiFi adding can be divided into smart link and AP connection.
- Page 5 ⚫ Smart link (it might be failing to connect when adding via this way due to the restriction of certain routers, if fails, you can try to connect with AP connection)： Select smart link→follow up with the instructions→connected WiFi successfully→input device default password (if no, you can create a new password according to instructions) →...
- Page 6 ⚫ Wired adding (recommend outdoor use) Select wired connection→select wanted device in new device listings→create device name & password→save. IV. Introduction of function buttons ④ ① ② ③ ①Weak password icon: Suggest to revise password when this icon is on. ②Defense succeeded &...
- Page 7 ⑥ ⑥ ① ② ③ ④ ⑤ ①Remote recording: Record videos and save it to phone. ②Intercom system: Press the button and you can talk remotely. ③Remote capturing: Capture video screenshot and save it to phone. ④Defense succeeded & disarming succeeded ⑤Memory point settings (it needs firmware support) ⑥You can adjust the monitoring direction with your finger sliding the screen up and down.
- Page 8 V. Settings Device information： Firmware version. We need to know firmware information when something happens to firmware. Time settings： Set device’s time and time zone. Picture and sound： set device video format、volume、video quality、motion detection sensitivity、reverse image、indicator light and so on. Security settings：...
- Page 9 alarm notification and alarm recording. Firmware update： Update & optimize device firmware. Change to standalone mode (this function needs device support)：It applies to the users without using router. You can get through via AP hot WiFi under this mode. ⚫ Users without router can access through device’s hotspot, details are as follows:...
- Page 10 VI. FAQ ① Q: Notice wrong password when checking real time videos. A: Device visiting password probably has been changed by other people but you can enter correct remote visiting password in the popup. If you forgot the password, you can press the “reset”...
- Page 11 prohibited or not by SafeMgr. ④ Q: What shall we do if motion detection gives misinformation? A: Update device firmware (above 14.0.07.76) and APP (above 00.46.00.13) so that you can adjust motion detection sensitivity in APP settings or revise configuration files md_ level = 3(1~6, the smaller, the more sensitive) ⑤...
