Operation Manual
19" Power Amplifiers with 2 to 8 Channels
Our PA series of multi-channel power amplifi ers comprises sophisticated class D amplifi ers
designed for use in AV systems, multi-room systems and multi-channel public address systems.
They deliver outstanding sound quality with low levels of heat build-up and provide an Auto ON/OFF
circuit for each channel pair to minimize power consumption in the SLEEP MODE.
The amplifi ers are equipped with almost completely silent, temperature-controlled fans and a
selectable input sensitivity of +4 dBU or –6 dBU for home audio application.
Integrated limiters monitor voltage, current and power at the speaker outputs and thus prevent
distortion and overload. To enable remote control, the amplifi ers are equipped with an ON/OFF
contact and VCA inputs with separate channels for external volume control.
1
Advertisement
Table of Contents
Related Manuals for lb Lautsprecher PA series
Summary of Contents for lb Lautsprecher PA series
- Page 1 Operation Manual 19“ Power Amplifiers with 2 to 8 Channels Our PA series of multi-channel power amplifi ers comprises sophisticated class D amplifi ers designed for use in AV systems, multi-room systems and multi-channel public address systems. They deliver outstanding sound quality with low levels of heat build-up and provide an Auto ON/OFF circuit for each channel pair to minimize power consumption in the SLEEP MODE.
-
Page 2: Table Of Contents
External Wiring of VCA Control Inputs ..........10 PA 4400 Block Diagram PA Series 2 to 8 Channels .......... 12 Technical Drawings 1 U and 2 U Power Amplifi ers ......13 Technical Drawings WP-V / RP-V / RP-1 U and DV Module ....14 PA 6100 Technical Drawings PA-T 100 / PA-T 200 / PA-T 400 / PA-T 1 U .. -
Page 3: Important Safety Information
Important Safety Information Please read the following instructions carefully before installing or connecting the unit! Components inside the device may generate high voltages which can lead to life-threatening electric shocks if touched. CAUTION! Service and repair work must only be carried out by qualified personnel. Do not open the case as there is a risk of electric shock. -
Page 4: Specifications - General
Specifications – General Inputs ..............INPUT and THRU per channel, XLR symmetric Nom. input level ..........–6 dBU/+4 dBU switchable Max. input level ..........+ 22 dBU Input impedance ..........20 kohms Load impedance ..........≥ 2 ohms/bridge ≥ 4 ohms Outputs .............. -
Page 5: Specifications - Model-Specific
Specifications – Model-Specific Model Case Output Power Power Consumption Weight Standby Sleep Idle 1/8 nom. Power Max. 4 ohms 2 × 100 watts 8 ohms 2 × 60 watts PA 2100 2 ohms 2 × 100 watts 6.9 kg bridge 1 ×... -
Page 6: Front Controls
Front Controls 1 Gain per Channel 7 PROTECT LEDs The gain controls have a logarithmic characteristic. The LEDs show an irregular state of the corresponding The nom. Sensitivity is related to MAX. amplifi er channel e.g. shortened output, DC at the output or damage. -
Page 7: Backside Controls
Backside Controls – Connectors per Channel Pair 1 Speaker Connectors 5.4 STEADY ON Fix the speaker cables to the screw-type terminals In the upper position the channel pairs operate in AUTO ON/OFF The speaker Impedance shouldn’t come signifi cantly below mode and switch automatically into an idle state (SLEEP) if the 2 ohms ( 4 ohms in bridge mode) input signal is absent for over 5 min. -
Page 8: Cleaning The Fan Filters
Cleaning the Fan Filters For cleaning the fan fi lters remove the front cover of the Caution! amplifi er Don’t operate amplifi ers without fi lter foam mats! 1 Unscrew the two fi xing screws and detach the front cover Don’t try to clean the fi... -
Page 9: Accessories
Accessories In wall volume control panel with ON/MUTE WP-V switch and LED RP-V Rack volume control panel with ON/MUTE switch and LED Rack cradle 19“, 1 U for up to 6 RP-modules RP-1 U DV-Modul Digital module for volume control via up/down contacts PA-T 100 100 V transformer module, 100 watts toroidal core. -
Page 10: External Wiring Of Vca Control Inputs
External Wiring of VCA Control Inputs 1-Channel Volume Control using WP-V or RP-V The control panels provide regulation from 0 to –80 dB and an on/off switch (ON/MUTE). “ON” is indicated by the green LED. Multichannel Volume Control using WP-V or RP-V One control panel can regulate several amplifi er channels in parallel. - Page 11 External Wiring of VCA Control Inputs Multichannel Volume Control using the DV Module Like the WP-V or RP-V panels also the DV module may control several amplifi er channels in parallel. 1-Channel Volume Control using a 0 – 10 V Dimmer Actuator with ON/OFF Contact A passive 0 –...
-
Page 12: Block Diagram Pa Series 2 To 8 Channels
Block Diagram PA Series 2 to 8 Channels... -
Page 13: Technical Drawings 1 U And 2 U Power Amplifi Ers
Technical Drawings Amplifiers 1 U / 2 U... -
Page 14: Technical Drawings Wp-V / Rp-V / Rp-1 U And Dv Module
Technical Drawings WP-V / RP-V / RP-1 U / DV Module WP-V RP-V RP-1 U DV Module... -
Page 15: Technical Drawings Pa-T 100 / Pa-T 200 / Pa-T 400 / Pa-T 1 U
Technical Drawings PA-T 100 / PA-T 200 / PA-T 400 / PA-T 1 U PA-T 100 PA-T 200 und PA-T 400 PA-T 1 U... - Page 16 Errors and omissions excepted. Specifications and design are subject to changes without prior notice. lb Lautsprecher und Beschallungstechnik GmbH info@lb-lautsprecher.de www.lb-lautsprecher.de Steinerstr. 15 K · 81369 Munich Germany Phone +49 89 1893109-0 · Fax -29 © lb Lautsprecher und Beschallungstechnik GmbH...
