S-4600 SDI to HDMI converter
1. Characteristics
◆
Portable 3G/HD/SD-SDI to HDMI converter
◆
1 SDI input, 1 SDI loop through output, 1 HDMI output,
Embed SDI audio to HDMI output
◆
SDI embedded audio output (3.5mm socket)
◆
2. Product View
Left side view
⑴
AUDIO OUT: Analog audio output (3.5mm)
HDMI OUT: HDMI output
⑵
SDI LOOP: 3G/HD/SD-SDI loopthrough output (BNC)
⑶
SDI IN: 3G/HD/SD-SDI input (BNC)
⑷
⑸
LED status indicator
DC 12V: 5.5mm pole DC input
⑹
USER MANUAL
SWIT Electronics Co., Ltd.
Front view
Tel:+86-25-85805753
Fax:+86-25-85805296
http://www.swit.cc
E-mail: contact@swit.cc
Right side view
