Start Guide

This camera is a delicate instrument and should be handled with care. When not in use, please store the camera
in a safe place with the dust cap attached. Do not let the camera get in contact with water or expose it to
extreme temperatures (below 0 or above 50 degrees Celsius). In order to receive the highest level of service,
please retain your receipt as proof of purchase.

Included Parts

Moticam
3
Moticam X
Calibration Slide
C-Ring
Motic Images CD
USB Cable and
Charger
X
3
Eyepiece Adapter (2)
Dust Cap
Focusable Lens
Macro Tube

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Moticam X3 and is the answer not in the manual?

Questions and answers

Related Manuals for Motic Moticam X3

Summary of Contents for Motic Moticam X3

  • Page 1 (below 0 or above 50 degrees Celsius). In order to receive the highest level of service, please retain your receipt as proof of purchase. Included Parts Moticam X Eyepiece Adapter (2) Calibration Slide Dust Cap C-Ring Focusable Lens Motic Images CD Macro Tube USB Cable and Charger...
  • Page 2 MoticamX Camera Specification Name MoticamX Notes Sensor Size 1/3 " CMOS Sensor 5.44 x 3.07 mm Effective area Pixels Size 2.0 x 2.0 um Resolutions 2592 x 1520 Still mode – MotiConnect, Browser, and Software 1920 x 1080 (Maximum Resolution) Live mode - MotiConnect 1280 x 720 1920 x 1080...
  • Page 3 Using the Camera On the eyepiece 1. Install the Motic Images Plus application program from the CD included. 2. Remove the Dust Cap from the camera and attach the focusable lens 3. Choose the right size eyepiece adapter and attach this to the focusable lens 4.
  • Page 4 1. Each Moticam X3 transmits its own WiFi signal to which you can directly connect your WiFi Device. 2. The Moticam X3’s SSID signal is printed on a label on the camera. To log into your camera, simply connect your WiFi device to that signal.
  • Page 5 3. When the MotiConnect webpage opens, select the configure tab. 4. Under Access Point, locate Channel. 5. By default the Channel will be either 1 or 6: See picture below  6. When using either Channel 1 or 6, the camera can be used in 2.4Ghz mode. Typically Channel 6 works best. 7.
  • Page 6 MOTICAM X3 Information:  The Moticam X3 by default operates in 2.4Ghz mode. 1. Allows for connection to devices without 5Ghz compatibility.  In 2.4GHz mode, frame rates will be much slower, comparable to the Moticam X and X2. ...
