Ansel 2012 Quick Start Manual

Wireless Access Point, Client Bridge
Quick Start Guide >>
ANSEL 2012 is a long range outdoor wireless Access Point / Client Bridge that
operates in both 5GHz and 2.4GHz frequency. It provides high bandwidth up to
54Mbps and features dual polarization antenna with high transmitted output
power as well as superior sensitivity. ANSEL 2012 extends radio coverage,
avoids unnecessary roaming between Access Points and ensures a stable
wireless connection while reduces the number of required equipments.
ANSEL 2012 provides user friendly interface including user friendly distance
control ranges from 1KM up to 30KM and RSSI LED indicator offering real time
signal status. It comes with PoE injector for convenient outdoor installation.
ANSEL 2012 enforces transmission security with full support of latest encryption
mechanism including 64/128/152-bit WEP, WPA and WPA2. With 13dBi internal
antenna and superior performance, ANSEL 2012 makes an optimal wireless
solution for both small and large scale projects.
IP Address Configuration
The default IP address of the device is
192.168.1.1. In order to log into this device, you
must first configure the TCP/IP settings of your
PC/Notebook.
1. In the control panel, double click Network
Connections and then double click on the
connection of your Network Interface
Card (NIC). You will then see the
following screen.
2. Select Internet Protocol (TCP/IP) and
then click on the Properties button. This
will allow you to configure the TCP/IP
settings of your PC/Notebook.
3. Select Use the following IP Address radio
button and then enter the IP address
(192.168.1.21) and subnet mask
(255.255.255.0). Ensure that the IP
address and subnet mask are on the
same subnet as the device.
4. Click on the OK button to close this
window, and once again to close LAN
properties window
Logging In
1. To configure the device through the web-
browser, enter the IP address of the
Bridge (default: 192.168.1.1) into the
address bar of the web-browser and
press Enter.
2. After connecting to the IP address, the
web-browser will display the login page.
Specify admin as the default User Name
and Password, and then click on the
Login button.
Administration
1. Click on the Administration link under
the Management section. This option
allows you to create a new user name
and password for the device. For security
it is highly recommended for security
reasons.
