Star Micronics T300 User Manual

Shoulder Strap T300
536 Nanatsushinya, Shimizu-ku, Shizuoka,
424-0066 Japan
Tel: (int+81)-54-347-0112
Fax: (int+81)-54-347-0409
 Shoulder Strap Parts Breakdown
Buckle
User's Manual
Hooks
Ring
Warning / Safety Guidelines
• Carry the printer with the shoulder strap diagonally across the chest.
(As shown in the illustration.)
Do not put the shoulder strap around or hang the printer from the neck.
• Keep away from children.
• Do not swing the printer by the shoulder strap.
 Installing the Shoulder Strap T300 on the SM-T300
1. Pull the hooks down on the SM-T300 in the direction of the arrows.
2. Feed the left side of the strap through the hook in the order of the numbers
below. Then, push at least two inches (50mm) of the loose
end through the buckle to secure it.
Ring
3
Buckle
1
3. Repeat Step 2 to secure the right side of the strap.
4. With both sides locked, adjust the strap length to the user's comfort. Hold
the buckle and pull it in the desired direction to make it longer or shorter.
NOTE: The strap will detach if it is not fed through the buckle. Take care to leave
approximately two inches (50mm) of slack so it remains secured.
Copyright © 2010-2011 Star Micronics Co., Ltd. im00051
4
2
Hook
