TempTrackr™ Wireless
System Kit
Quick Setup Guide and
Operation Manual
The TempTrackr™ Multipoint Starter kit includes:
•
Three or Six wireless temperature sensors
•
One wireless interrogation unit
•
One dipole interrogation antenna
•
One RS232/RS485 cable
•
One software CD with the TempTrackr™ Wireless
Interrogation Software
Please contact SenGenuity if any item is either missing
or damaged. The wireless interrogation unit needs to be
powered by a 5V±5% DC power-supply. All temperature
sensors are interrogated by one interrogation antenna.
The TempTrackr™ Starter Kit can be setup in three simple
steps:
1.
Install and Configure TempTrackr™ Wireless Interrogation Software
2.
Setup and connect wireless interrogation unit
3.
Setup, locate and calibrate wireless sensors
267 Lowell Rd, Hudson NH 03051, USA
|
Phone: 1.888.328.7661
|
Helping Customers Innovate, Improve & Grow
Fax: 1.888.329.8328
|
www.sengenuity.com
Advertisement
Summary of Contents for SenGenuity TempTrackr
- Page 1 The wireless interrogation unit needs to be powered by a 5V±5% DC power-supply. All temperature sensors are interrogated by one interrogation antenna. The TempTrackr™ Starter Kit can be setup in three simple steps: Install and Configure TempTrackr™ Wireless Interrogation Software...
- Page 2 Please use the InstallShield Wizard, shown in Figure 2, to complete the installation process. Successful installation will result in the creation of a directory called TempTrackr in the path C:\Program Files\Sengenuity\TempTrackr. Start the Software from the Windows Start Menu or by double- clicking the WSR-T2 icon from the directory in which the software has been installed.
- Page 3 NOT connected please do not use it if you are in the United States. You WILL be in violation of FCC regulations. Please contact SenGenuity to arrange for a replacement kit to be sent to you.
- Page 4 ● Ensure that the distance between Interrogator Antenna and nearest parallel metal wall >4” (~10 cm). Figure 8: Incorrect and Correct Setup 267 Lowell Rd, Hudson NH 03051, USA Phone: 1.888.328.7661 Fax: 1.888.329.8328 www.sengenuity.com...
- Page 5 Calibration Screen. Alternately, the CE compliant version allows the user to only select sensors that operate in the 433MHz band. Figure 11: Calibration Screen - with FCC version 267 Lowell Rd, Hudson NH 03051, USA Phone: 1.888.328.7661 Fax: 1.888.329.8328 www.sengenuity.com...
- Page 6 You can store these settings in a ‘settings file’ by pressing the ... button in the setting section and specifying a file name. The software and the system are now ready to track temperature. Figure 14: Measure 267 Lowell Rd, Hudson NH 03051, USA Phone: 1.888.328.7661 Fax: 1.888.329.8328 www.sengenuity.com...
-
Page 7: Safety Precautions And Warnings
In compliance to Agency certification and requirements for operating safety warning instructions, SenGenuity is providing the following information for the safe operation of the TempTrackr™ Wireless Multipoint System Kit and Wireless Interrogation Unit. This information applies to all models/configurations of the TempTrackr™ Wireless Multipoint System system and stand-alone Wireless Interrogation Units (Model WSR-T2), used either as a SenGenuity-furnished turn-key system or when integrated into users’... - Page 8 Conformément à la réglementation d'Industrie Canada, le présent amplificateur de puissance radiofréquence peut être utilisé seulement avec un émetteur avec lequel il a été certifié par Industrie Canada. Le numéro d'identification d'Industrie Canada pour l'émetteur avec lequel l'amplificateur est autorisé à fonctionner est IC : XX…X-YY…Y. Conformément à...
