- Page 1 Air Lift Performance ® ® C o n t r o l S y s t e m U S E R G U I D E For maximum effectiveness and safety, please read these instructions completely before operating. Failure to read these instructions can result in an incorrect installation.
-
Page 2: Table Of Contents
Smartphone App for 3S . . . . . . . . . . . . . . . . . . -
Page 3: Introduction
ALP3 display, AutoPilot V2, smartphone app only and for use with an aftermarket controller such as an AVS switch box. No matter which version is purchased, the 3S system will work with the free Air Lift Performance smartphone app for Apple iOS or Android. The system is not directly compatible with existing ALP3 and APV2 displays. -
Page 4: Smartphone App For 3S
Only one device can be paired to the manifold at a time. Once the manifold is in pairing mode, go Android to the devices menu in the 3S App and select the 3S manifold under the devices found list. AD-955... -
Page 5: App Navigation
3S User Guide APP NAVIGATION User-defined Button Double tap to (See Page 7 All-Up Button) activate presets Manually increase Manually increase and decrease and decrease front front left air spring right air spring pressure. pressure. Preset Ride Preset High (Middle Button)*... -
Page 6: Changing Presets
Android to enter the desired value. 3S includes three programmable, stored presets which allow you to make quick system adjustments using valve open times. This feature can only be set up using the app but the presets can be triggered using the app or ALP3 display. -
Page 7: Alp3 Display For 3S
3S User Guide ALP3 Display for 3S The ALP3 display for 3S is the basic function version of Air Lift Performance’s award-winning top-line air management system. User-defined Double tap to Button activate presets (See Page 10 All-Up Button) Manually increase... -
Page 8: Getting Started
3S User Guide GETTING STARTED 1. To get to the main menu screen, push the middle (preset ride) button simultaneously with either the up (preset high) button or down (preset low) button. 2. All other settings and parameters will be detailed in the following pages to ensure the system is set up accurately. -
Page 9: Display
3S User Guide DISPLAY Brightness Set the brightness for the display while in use. 1. Level 1-10 2. Use the up and down buttons to increase or decrease luminosity in 10% increments. 3. Level 7 (default) Brightness Sleeping Set the brightness for the display after it goes into sleep mode. -
Page 10: About
Bluetooth identification address. Users may need to provide this information when calling Air Lift Company customer service. Firmware on the 3S display can be updated for use with the 3H system. AD-955... -
Page 11: Additional Information
ADDITIONAL INFORMATION Use of the System Air Lift Performance 3S is a manual adjustment system. There are no pressure sensors built into 3S, so the system will not make automatic adjustments. Presets can be used to configure the amount of time the valves are open. -
Page 12: Apv2 For 3S
3S User Guide APV2 for 3S OPERATING THE SYSTEM There is only one operation mode: Manual. After 10 seconds of non-use, the display enters standby where the LCD dims. Push any button to “wake up” the display and allow users to activate the system. The display will remain on for one minute after the ignition is turned off. -
Page 13: Backlight Setting
3S User Guide BACKLIGHT SETTING Press buttons 1 and 5 to enter BACKLIGHT BACKLIGHT. Set display backlight to your preference by pressing the + and – on QUIT R (Red), G (Green), B (Blue). Press buttons (1+5) simultaneously to return to the main screen. -
Page 14: Manual Switch Box
3S User Guide Manual Switch Box Air Lift Performance 3S can be used with a manual switch box such as AVS. The manifold switch inputs require 12V (+) for activation. The Air Lift Performance 3S is compatible with any manual switch box that switches 12V (+) to the manifold input wires. -
Page 15: Troubleshooting Guide
3S User Guide Troubleshooting Guide For further technical assistance contact Air Lift customer service by calling (800) 248-0892, Monday through Saturday. For calls from outside the USA or Canada, dial (517) 322-2144. PROBLEM CAUSE SOLUTION Nothing happens when the There is a blown fuse or... - Page 16 USA or Canada, dial (517) 322-2144. Thank you for purchasing Air Lift Performance products! Air Lift Performance • 2727 Snow Road • Lansing, MI 48917 or P.O. Box 80167 • Lansing, MI 48908-0167 Toll Free (800) 248-0892 • Overseas (517) 322-2144 Fax (517) 322-0240 •...
