TV STAND
EN
ASSEMBLY INSTRUCTIONS
For:
FS052W
FS052B
v.16.3
Component Checklist
IMPORTANT: Ensure that you have received all parts according to the component checklist prior to installation.
If any parts are missing or faulty, telephone your local distributor for a replacement.
top plate (1x)
A
Spacer tube (4x)
screw (4x)
C
D
40kg
(88lbs)
RATED
bottom plate (backwards) (1x)
B
Allen Key (1x)
Threaded rod (4x)
E
F
Screw the threaded rods.
screw in
F
A x 1
A
F x 4
Putting on the spacer tubes.
put on
C
C x 4
Assembly bottom plate.
B
B x 1
D x 4
Flip over the mounted tv-stand.
5
Done.
360°
E
D
screw in
Thanks to the rotating device, the
TV stand can be rotated 360 °.
