Page 1: Table Of Contents
Battery Charging Video Mode Normal Recording Loop Recording Picture Mode Slow Motion Mode Menu Setting Install and Use CG360 Applications Smart phone CG360 application Windows CG360 application Connect HDMI Playback on PC Technical specification Precaution Please read through the following guidelines prior to using the camera.
Page 2: Camera Interface
Camera Interface Button Function Power button： Long press to turn on or turn off the camera In standby mode - short press to switch into Video/Picture/Slow Motion/Menu Mode In menu mode - short press to switch between Video menu/Picture menu/Function menu/System menu and Exit Shutter button：...
Page 3: Camera Operation
Camera Operation Power on/off Power on: Long press power button, the display illuminates with a beep, camera enters standby mode. Power off: When camera is on, long press power button to switch the camera off. Battery Charging Connect camera with power charger via USB cable, the camera will power on automatically.
Page 4: Slow Motion Mode
Camera default setting is Video mode. In standby mode, short press Power button once to enter picture mode, aim at the object you want to shoot and press Shutter button, camera will save pictures automatically. Slow Motion Mode The camera is in a locked setting and will take video in 1440p 60fps and the video will be played in 1440p 30fps.
Page 5: Install And Use Cg360 Applications
Install and Use CG360 Applications Smart phone mobile application  Search for "CG360" in Google Play or Apple App Store to download and install CG360 application.  Long press Up button on the camera to turn on Wi-Fi, the screen displays the Wi-Fi icon.
Page 6 CG360 Application Interface 1. Gyroscope Mode: The gyroscope function is used to determine the phone position using gyroscope data; you can toggle this on/off to change the viewing experience. 2.Invert Mode: The picture will be rotated 180 degrees; you can toggle this on/off to change the viewing experience.
Page 7 Note: Be sure to select either “Phone” or “CG360” at the top of the application to determine where you will be playing back the files from.
Page 8: Windows Cg360 Application
Contains all the standard features of the mobile phone application. The special video effects can be used on an ordinary video player. Supports playback offline. Software Installation:  Download Windows desktop CG360 application to your computer. To find your compatible version for download, please go to: http://www.cyclopsgear.com/get-support/software Operation: ...
Page 9: Connect Hdmi
pic1 pic2 pic3 pic4 Connect via HDMI Connect the camera to an HDMI TV via an HDMI cable. All operations can be displayed in high definition on an HDMI TV screen. Note: Support for preview and playback ONLY, you cannot take videos or pictures. Playback on PC Connect the camera to a PC via the provided USB cable.
Page 10: Technical Specification
Technical specification Dimension 45mm*44mm*56mm Allwinner V3 Sensor SONY IMX179 Lens 220°FOV Image size 16M / 12M / 8M / 5M 2448×2448 30fps (1:1) 2048×2048 30fps (1:1) 1440×1440 60fps (1:1) 1440×1440 30fps (1:1) 1072×1072 60fps (1:1) Resolution 1072×1072 30fps (1:1) Screen 0.96 inch LCD screen Waterproof Audio...
