Summary of Contents for Tin Knocker TK 816
- Page 1 TIN KNOCKER TK 816 LEAF BRAKE INSTRUCTIONS & PARTS DIAGRAM TAAG MACHINERY CO. (Master Distributor) 1257-B Activity Dr. Vista, CA 92081 Tel: (800) 640-0746 Fax: (760) 727-9948 Website: www.tinknocker.com * Email: taag@sbcglobal.net 01082007 mod 1...
-
Page 2: Safety Rules
TIN KNOCKER SAFETY RULES TK 816 LEAF BRAKE 1. Never use a machine or tool for anything other than its intended purpose. Use the proper tool and equipment for the task. 2. Do not operate the machine in excess of its rated capacity. - Page 3 DO NOT use the Leaf Brake to bend rods, nails or wires. This will cause damage to the edge of the top blade. DO NOT exceed the capacity of the Leaf Brake. OPERATING & ADJUSTMENT OF THE TK 816 Adjusting for Metal Thickness Clearance for bends is obtained by moving Top Leaf back at bending edge.
- Page 4 Creeping Top Leaf Adjustments Should Top Leaf creep forward when clamping material: 1. Check that brake sets level on floor. 2. Check Top Adjustment Plate (M) and Top Adjustment Bolts and Lock Nuts (L) to eliminate any movement of step bracket (15). 3.
- Page 6 Parts For 816 Leaf Brakes Fine Part Description REQ"D. 816101 801 Holddown Assy. 816102 Top Blade 816103 Screw 816134 Toggle Assy. Nut 816104 Spring Cover Assy. Bolt 816105 Spring Cover Assy. 816106 Clamp Handle R.H. 816107 Clamp Handle L.H. 816108 Toggle Assy.
