SleepSense PVDF Effort Sensor User Manual

Warranty: SLP warrants the respiration effort sensor to be free of defects in materials and workmanship
for a period of 12 months from the date purchased. The sole liability of SLP and our distributor(s) is
limited to replacement or repair of the product at the option of SLP with no charge for parts or labor if
any part is proven to be defective in workmanship, performance, or materials during the warranty period.
Under no circumstances shall SLP or our distributor(s) be liable for any loss of revenues or damage,
direct, consequential, or incidental, including loss of profit, property damage, or personal injury arising
from the use of, or the inability to use this product. This warranty is intended only for the original buyer
and is in lieu of all other warranties or previous agreements, expressed or implied. This warranty is
rendered void if the product is used for other than its intended purpose or is subject to abuse, misuse,
tampering, neglect, or unauthorized modifications. Use of this product constitutes acceptance of this
warranty in total.
For more information
S.L.P. Ltd. S.L.P. Inc.
62 Anilevitz St, 2511 Technology Dr., Suite 112
Tel Aviv, 6706016, Elgin, IL 60124, USA
ISRAEL Tel: +1 (630) 513 7479
Tel: +972 3 6870640 Fax: +1 (630) 513 8478
Fax: +972 3 5371282 E-mail: info@sleepsense.com
www.sleepsense.com Toll-free(U.S.): 888-slp-sens (757 7367)
PVDF Effort Sensor - Double loop / Safety DIN connectors
Technical specifications:
Item #:
Cable:
Sensor:
System connector:
Recommended filter settings:
EC REP
Medes Limited
Signal output:
5 Beaumont Gate,
Shenley Hill, Radlett, Intended for system:
Herts WD7 7AR, England
Operating conditions:
Tel: +423-663-169205
Tel/Fax: +44 19238 59810
Storage temperature:
Operating and storage humidity:
Effort Sensors
The Sensor Solution Company

User Manual

1389
200 cm long white PVC insulation lead wire
6"x1.5" black elastic band
1.5 mm DIN safety DIN
High pass: 0.1 Hz / Low pass: 70 Hz
Approximately 1 mV for normal respiration
Any system that accepts DIN safety pins
5ºC (40ºF) - 40ºC (104ºF)
-20ºC (-4ºF) - 60ºC (140ºF)
5% - 95% (Non-condensing)
