CAT.5 Cable (cross over cable to NIC or
straight through cable to Hub/Switch)
LED indicator (Power)
LED indicator
Figure 4 Fundamental connection of ODU
Tel: +886-2-29101997
Fax:+886-2-29103996
Email:sales@azuretec.com
www.azuretec.com / www.azuretec.com.tw
12VDC (2.4GHz 0.1W/0.5W)
15VDC (2.4GHz 1W; 5.8GHz 0.2W/0.5W)
30VDC (2.4GHz 2W/4W)
Connect PoE to the ODU by SFTP cable
)
N-type connector (to Antenna
WR200 Series
WLAN Outdoor Radio
Installation Guide
Help you to set the outdoor radio
correctly and quickly.
Version 2.0
Advertisement
Table of Contents
Summary of Contents for Azuretec WR200 series
- Page 1 CAT.5 Cable (cross over cable to NIC or straight through cable to Hub/Switch) 12VDC (2.4GHz 0.1W/0.5W) 15VDC (2.4GHz 1W; 5.8GHz 0.2W/0.5W) WR200 Series 30VDC (2.4GHz 2W/4W) WLAN Outdoor Radio Installation Guide LED indicator (Power) Help you to set the outdoor radio correctly and quickly.
- Page 2 Thank you for purchasing our product. Upon receiving the package, please check whether the unit is completed with the following components: PoE (Power over Ethernet) Power Adapter Power Cord Mounting Kit SFTP Cable(Optional) Product CD Quick Installation Guide Figure 3 cable’s mounting Standard installation involves the following steps Step1.
