Summary of Contents for AnaCom AnaSat SSPA series
- Page 1 ® AnaSat SSPA Series Operating Manual Ku-Band SEKu-Band EC-Band SEC-Band...
- Page 2 2008 AnaCom, Inc. All rights reserved. The information furnished by AnaCom, Incorporated, in this publication is believed to be accurate and reliable. However, no responsibility is assumed by AnaCom for its use, nor any infringements of patents or other rights of third parties resulting from its use. No license is granted by implication or otherwise under any patent or patent right of AnaCom, Inc.
-
Page 3: Table Of Contents
1961 Concourse Dr. San Jose, CA 95131 Tel: (408) 519-2062 Fax: (408) 519-2063 3133503 Operating Manual for the AnaSat ® -Series SSPA Table of Contents Table of Contents ......................... 3 Introduction .......................... 6 Typical Operating Parameters – AnaSat SSPAs ..............7 Installation .......................... - Page 4 3133503 Maintenance ........................18 Fan Replacement ........................18 Alarm Relay Closure ......................19 Monitored Values ....................... 19 Data Terminal Connection ....................19 Terminal Display ....................... 19 RS232 Serial Port Weather-tight Connector ..............20 RS485/RS232 Selection ..................... 21 Emissions and Immunity Regulation Conformance ............22 Standards Met: ........................
- Page 5 3133503 ® AnaAat SSPA Quick Start Guide 1. Mount the SSPA on the antenna. 2. Connect the cables for RF input, and RF output (waveguide). 3. If needed, connect the M&C or PA MONITOR to the driver or Protection Switch. 4.
-
Page 6: Introduction
3133503 Introduction The AnaSat VSAT series of SSPAs are designed for continuous outdoor duty in all types of ® environments. Ideally suited for SCPC, MCPC, DAMA, and VoIP applications. Designed to interface with a 0 dBm driver, the AnaSat VSAT SSPA may be used in a wide variety of communication ®... -
Page 7: Typical Operating Parameters - Anasat Sspas
3133503 Typical Operating Parameters – AnaSat SSPAs EC/SEC-Band Ku/SEKu-Band 1 dB Compression Point 10W: 40 dBm 40 dB TX Gain 1 dB Compression Point 8W: 39 dBm 39 dB TX Gain 20W: 43 dBm 43 dB 16W: 42 dBm 42 dB 30W: 44.8 dBm 44.8 dB 20W: 43 dBm... -
Page 8: Installation
SSPA is properly grounded. Do not rely on coaxial cable shields for the ® ground connection. If the cover is removed from any ANACOM product, ensure that all: gaskets are intact and free of damage prior to reinstallation ... -
Page 9: Power Amplifier
ANTENNA INSTALLATION AND WHENEVER WORKING ON OR AROUND THE SYSTEM. Site Considerations The installation requirements of any particular site are the responsibility of the system operator. AnaCom offers an optional installation mounting kit, that can be used at most sites. Contact AnaCom for details. Antenna The SSPA must be attached to some form of mounting structure which is usually the antenna feed boom or the antenna support structure. -
Page 10: Sspa Mounting Considerations
3133503 SSPA Mounting Considerations The AnaSat SSPA must be mounted such that: ® 1. Sufficient support is afforded the Block Up-Converter to minimize the effects of antenna sway in strong winds. 2. Air movement is possible across the heat sink fins. Ideally, the fins should be aligned vertically, but this is not required. - Page 11 Channel SSPA Threaded 3/8 rod, SS, 12in long Tube, 7in x 0.7in dia, steel Washer, flat, 3/8 SS Washer, split, 3/8 SS Nut, 3/8 SS ANACOM INC. 150 Knowles Dr. Los Title ASSEMBLY DRAWING, SINGLE MOUNTING KIT Size Document 31626...
- Page 12 3133503 Figure 3b – Single Mount for a Kingpost ® AnaSat SSPA...
- Page 13 3133503 Figure 3c – 1+1 Mount for a Kingpost ® AnaSat SSPA...
-
Page 14: Cable And Waveguide Connections
3133503 Cable and Waveguide Connections Cabling Requirements Local regulations may require that cables in occupied buildings be installed in steel conduit. Local government agencies may waive this requirement for the use of Plenum cables, which are standard cables entirely encased in solid Teflon. Check the codes in your area. NOTE: E QUIPMENT OUTAGES DUE TO FAULTY CABLE MATERIALS OR INSTALLATION ARE NOT COVERED BY YOUR WARRANTY... -
Page 15: Transmitter Feed
3133503 Figure 5 - Diagram of AC power cable Transmitter Feed If using an SSPA with an N-type connector output, connect a section of coax between the OMT transmit port and the SSPA’s transmit port. If using a SSPA with a waveguide flange output port, connect a section of waveguide between the OMT transmit port and the SSPA’s transmit output, TX OUT. -
Page 16: Final Check
3133503 Final Check Recheck all bolts and cabling. After all other connections have been made (TX RF input, TX RF output, and grounding), connect the AC power cord to an active outlet. Water Resistance Wrap The application of moisture-resistant wrap (mastic tape) to all connectors is recommended to prevent water entry and resultant water damage. -
Page 17: Operation
3133503 Operation After the AnaSat hardware is mounted and verified, the antenna must be aimed toward the ® desired satellite. Follow the antenna/mount manufacturer’s instructions, using coordinates provided by the satellite operator. Do not transmit until you have received authorization from the satellite network operation center, and a transmit power level from its engineering staff. -
Page 18: Maintenance
A replacement fan available from AnaCom, Inc., can then be mounted on the shroud and it’s connector plugged into the receptacle on the heatsink. The shroud can then be re-attached to the heatsink using the original screws. -
Page 19: Alarm Relay Closure
3133503 Alarm Relay Closure A mechanical relay is used in the AnaSat ® SSPA for alarm indication. The red LED mounted on the SSPA is illuminated whenever a problem exists and the relay has closed. The alarm relay has normally closed contacts, so it defaults to the alarm state when power is off. The alarm relay is accessible through the 18-pin connector mounted on the SSPA chassis. -
Page 20: Rs232 Serial Port Weather-Tight Connector
3133503 “ON” indicates the SSPA will transmit when all alarms are cleared. This is the normal setting. “OFF” indicates the SSPA will not turn on even if all alarms are clear. This can be saved across a reboot using the SAVE command. ... -
Page 21: Rs485/Rs232 Selection
3133503 18-Pin Circular Weathertight Connector An 18-pin circular connector is used for monitoring the alarm C-Form relay. Only some of the pins are used, but the same connector is used to maintain consistency with the protection switch used in the AnaSat ® product line. 10 11 17 18 Cable Wire View... -
Page 22: Emissions And Immunity Regulation Conformance
3133503 Emissions and Immunity Regulation Conformance AnaCom SSPA products conform to the following CE standards listed below: Standards Met: Emissions Regulations 1. Power Line Conducted Emissions per EN55022: 2003 Class A 2. Open Field Radiated Emissions per EN55022: 2003 Class A 3. -
Page 23: Limited Warranty
LIMITED WARRANTY If this product should fail due to defects in materials or workmanship, AnaCom, Inc., will, at its sole option, repair or replace it with new or rebuilt parts free of charge for a period of two (2) years from the date of shipment from the AnaCom factory.
