Page 1 HIGH SPEED DOME CAMERA User Manual 27X AF Zoom...
Page 3: Table Of Contents
Table of contents Ⅰ CAUTION --------- Ⅱ INTRODUCTION OF PRODUCTS --------- DIRECTIONS FOR USE Ⅲ --------- 14 FUNCTIONAL SETTING BY THE KEYBOARD Ⅳ --------- 26 OSD MESSAGE DISCRIPTION Ⅴ --------- 29 TROUBLE SHOOTING Ⅵ --------- 31 DIMENSION Ⅶ --------- 33 ASSEMBLY Ⅷ...
Page 4: Ⅰ Caution
Ⅰ. CAUTION Thank you for purchasing our product. Please operate the product after being fully aware of the manual. Pease contact us if you have any queries. Precaution Note the following matters before the installation of the product. Avoid the following places for the installation. A high/low temperature: Using indoor-cameras Snow, rain and wet: Humidity or water and in the places of +50°C~ -10°C can cause...
Page 5 Caution in Use Do not disassemble the unit and put alien substances in the unit. Disassembling the unit or putting alien substances such as a metal can make the camera defective. - Make sure of power switch-off before the installation. : Ensure power switch-off and check the voltage the camera before the installation.
Page 6: Ⅱ Introduction Of Products
1. DESCRIPTION AND FEATURES Description This camera has been designed elegantly for buildings, department stores that need to be in harmony with the interior as a high speed dome camera, including various observation functions. Features ☺ Optical 27X Zoom Rate Built-in 27X Zoom Camera with 12x Digital Zoom (Total 324x Zoom ) ☺...
Page 7 2. INSTALLATION AND CONNECTION 1) Name and function of each part Indoor Type Outdoor Type (UPPER COVER) The camera’s body goes to here and a power cable, data cable, video cable, sensor have been connected with this (DOME DRIVER) A main body that has a built-in the control units and camera (LOWER COVER)
Page 8 2) Installation Indoor Type Outdoor Type SEPARATION OF LOWER COVER (Indoor type) Loosen the bolt of the back lower cover screwdriver(+), then turn the cover as above the picture and pull the lower cover to the down (Outdoor type) Loosen the four bolts of the lower cover, then separate.
Page 9 Open the connector cover, then connect power, data, video cable and sensor The cover is opened if user loosens the one bolt on the connector cover by using a screwdriver(+). The bolts not loosened completely to protect from missing of them. Be careful that each cable which each function is changed wrong Have you connect the power cable...
Page 10 3) How to connect equipments DC12V/1A adaptor and junction box are provided on a purchase, Junction box consists of 2 data ports ( Each data port can be connected with maximum up to 128 cameras and sub keyboard terminal Connect the image line of a monitor Reference to the following page.
Page 11 Alarm output is tangency output of relay non-load, it can be used up to AC220/10A by connecting the load. The switch is automatically turned on when the sensor works and it is possible to cancel by using the controller after a limited The sensor time Can be connected maximum 4 channels and the camera...
Page 12 4) HOW TO SET PROTOCOL You have to change this switch when you Use to change this switch Protocol change protocol and communication speed A D D R E S S The switch to select The switch to select Change No.3 of S2 to INIT if user protocol baud rate wants to change protocol...
Page 13 5) SETTING ADDRESS OF DIP SWITCHES DIP SWITCH (HEX) DIP SWITCH (HEX) -No.1 is changed to No.64 and the last No.64 is changed No.128 when No.7 DIP SW is on. -No.1 is changed to No.129 when No.7 DIP SW is off and No.8 DIP SW is on. -No.1 is changed to No.193 and user can set up to maximum 255 ADDRESS when No.7, 8 DIP SW are on.
Page 14: Ⅲ Directions For Use
Ⅲ. DIRECTIONS FOR USE ● OSD (ON SCREEN DISPLAY) menu control It is the function to call up the Menu ＊User can not only set Preset, Group, Tour, Swing, Trace functions of the camera up by the menu, but also set them up by shortening keys.
Page 15 1. ID SET. This function is to set ◄◄ CAMERA SETUP p1 ►► 1. ID Set : CAM-001 camera ID up to 16 2. OSD Display. : ON letters on the monitor. 3. H-V Reverse. : Normal 4. AGC level. : Low User can choose letters 5.
Page 16 5. SHUTTER SPEED ◄◄ CAMERA SETUP p1 ►► As a setting shutter speed mode, it can be distinguished a fast 1. ID Set : CAM-001 2. OSD Display. : ON moving subject easily by means of shutter speed up. 3. H-V Reverse. : Normal ※...
Page 17 9. DNR Control ◄◄ CAMERA SETUP p1 ►► 1. ID Set : CAM-001 It can remarkably reduce noise of minimum illumination by super 2. OSD Display. : ON noise removable technique and also file size becomes smaller while 3. H-V Reverse. : Normal 4.
Page 18 ◄◄ CAMERA SETUP p2 ►► 12. WHITE BALANCE 10. Back Light : off 11. Set Back Light Mode It prevents from that white color is changed as illumination, user can 12. White Balance : Outdoor set it up in 2 ways. 13.
Page 19 16. DAY& NIGHT ◄◄ CAMERA SETUP p2 ►► The function is used to distinguish an object clearly in the dark 10. Back Light : off condition. 11. Set Back Light Mode 12. White Balance : Outdoor ▶ Auto-Low : This mode is worked automatically according to 13.
Page 20 20. PRESET SET & RUN PAGE ◄◄ CAMERA SETUP p2 ►► 18. Select Alarm : Sensor It is a function to set and operate Preset, Group, Tour. 19. Motion Detection : Off User can see the screen when moves the joystick to Right/Left after 20.
Page 21 ③ Preset Swing SET : Set Preset Swing Move next SWING page for the setting, if user presses F/F key in the state of selection of the menu ※The preset must be set before the setting as Swing Is a function to repeat an auto observation of 2 Preset points user fixes in Preset set ④...
Page 22 ⑤ Tour SET Group: User can set continual Group motion that can be put 12 Groups in 1 Tour Move to the setting page if user presses F/F key on this menu ■ The Group user wants to set must be set firstly ※Setting is only possible when Preset is set first in the state of setting of Swing, Group, Tour, otherwise, it displays the message “Sorry Undefined”.
Page 23 22. ALRAM CHANNEL ON/OFF ◄◄ CAMERA SETUP p2 ►► 18. Select Alarm : Sensor 19. Motion Detection : Off 20. Preset Set & Run Page 21.Trace Set Page 22. Alarm CH On/Off Page 23. Alarm Preset Set Page - CH On/Off : Alarm Input – Each channel can be ON/OFF - PREV MENU PAGE - Alarm Relay : It can be set On or not when ALARM OUTOUT - NEXT MENU PAGE...
Page 24 ※You can set ALARM setting MENU not only in CAMERA SET MENU MODE, but also a KEYBOARD in direct ◄◄ CAMERA SETUP p2 ►► 24. AUTO TILT MOVE 24. Auto Tilt Mode : Off The PAN is turned in a 180° degree arc automatically when the 25.
Page 25 ◄◄ CAMERA SETUP p2 ►► 28. SHORTCUT KEY 24. Auto Tilt Mode : Off 25. Smart Pan/tilt : ON The Shortcut Key can make some of the functions to perform faster 26. Manual P/T Speed : Max 27. Auto Refresh Time :1day and easily.
Page 26 31. FACTORY RESET WARNING ◄◄ CAMERA SETUP p2 ►► Please be careful of that all setting data of OSD MENU are reset 24. Auto Tilt Mode : Off 25. Smart Pan/tilt : ON into the first default when operates FACTORY RESET WARNING. 26.
Page 27: Ⅳ Functional Setting By The Keyboard
Ⅳ. Functional Setting by the Keyboard 1. Preset setting You can set Preset point up to 250. Preset Input. ① Preset setting can be set 1 to 250 sequentially after moves the camera to where you want ② Preset Move The camera moves to the preset point, if you press Preset No.
Page 28 ② Operation of Swing ③ End of Swing (Run Pan) (Run Tilt) 3. Group setting ① Start Group setting mode Start the Group Select the Group in 1~12 Select in Preset No.1~250 setting mode and input them. Move Speed: Dwell Time: The Speed from A to B The dwell time at the point of 64=High, 1=Low...
Page 29 EX). Register Group No. 1, 3, 6 as Tour Register Start Register Register Finish Tour No.2 Tour No.3 Tour mode Tour mode Tour No.1 ② Start / End Tour ③ Delete Tour Start Tour Finish Tour 5. Spiral Function It is a function to observe objects in the spiral direction. Spiral observation ‘ON’...
Page 30: Ⅴ Osd Message Discription
Ⅴ. OSD MESSAGE DISCRIPTION 1. PRESET MESSAGE CAM-001 CAM-001 CAM-001 SET PST 001 PRESET 001 CLEAR PST 001 User check that displayed when It is displayed when user preset No.1 is saved as an moving to the preset No.1 deletes preset No.1. the “...
Page 31 CAM-001 CAM-001 CAM-001 SET TOUR GP:01 TOUR&GP:01 PRESET:001 CLEAR TOUR & GRP As the message in the time It shows the data in group As the message in the of operation of Tour set, and tour saved was deleted. time of operation of tour “GP:01”...
Page 32: Ⅵ Trouble Shooting
Ⅵ. TROUBLE SHOOTING 1. You must turn off the power switch before installation of this equipment 2. Avoid installation places where it is the ultimate cold, hot, and humid. 3. Use a power supply of AC24V, 1.5A output. 4. Please be careful that you connect respective wires without mismatching in installation. 5.
Page 33 When it occurred alarm state, it is not Did you set the preset in the set Check setting status of the alarm exactly presser position or different. mode? preset in the set mode. When it activate alarm state, there is Did you use the exclusive control It is need to use an exclusive control no sign on the keyboard controller...
Page 34: Ⅶ Dimension
Ⅶ. DIMENSIONS Wall mount bracket Outdoor Type Indoor Type...
Page 35 Ceiling mount bracket Indoor Type Outdoor Type In-ceiling mount bracket...
Page 36: Ⅷ Assembly
Ⅷ. ASSEMBLY DSC-30EWP Wall mount bracket Remove ① main body camera from the housing ③ Fix the upper cover into a wall bracket with turning it in the same direction as the picture ④ Connect the data cable, video cable and power source cable. ②...
Page 37 DSC-20ECP Wall mount bracket Assembly of outdoor dome with pole mount pendant Remove Main body of The camera Turn the ceiling From the Housing. pole to connect. Fix the pole ceiling. Turn the joint coupler connect. Turn the cover coupler connect.
Page 38 Main & Sub Keyboard configuration...
Page 39: Ⅸ Specification
Ⅸ. SPECIFICATIONS MODEL 27X Auto Focus Zoom Signal system NTSC Image sensor 1/4” Sony Super HAD Color CCD Effective pixels 768(H) X 494(V), 752(H) X 582(V), Horizontal resolution Color : 550 TVL, B/W 680 TVL Lens 27x Optical zoom, f =3.5 –94.5 mm Digital zoom 12x (Total zoom 324x) Angle of view...
