Track Rocker Installation Instructions
58101: 8-Switch Customizable Track Rocker Switch Panel
58104: 6-Switch Customizable Track Rocker Switch Panel
58107: 4-Switch Customizable Track Rocker Switch Panel
Painless Performance Products recommends you, the installer, read this installation
manual from front to back before installing this harness.
For Installing Painless Part Numbers:
w/ Panel Dash Mount
w/ Panel Dash Mount
w/ Panel Dash Mount
Manual 90638
Advertisement
Summary of Contents for Painless Track Rocker series
- Page 1 58104: 6-Switch Customizable Track Rocker Switch Panel w/ Panel Dash Mount 58107: 4-Switch Customizable Track Rocker Switch Panel w/ Panel Dash Mount Manual 90638 Painless Performance Products recommends you, the installer, read this installation manual from front to back before installing this harness.
- Page 3 E-Mail: painless@painlessperformance.com If you have any questions concerning the installation of this product, feel free to call Painless Performance Products' tech line at 1-800-423- 9696. Calls are answered from 8 am to 5 pm central time, Monday thru Thursday, 8am-4: 30 pm Friday, except holidays.
-
Page 4: Table Of Contents
PAGE # SECTION CONTENTS OF THE PAINLESS KIT TOOLS NEEDED INSTALLING FACTORY STYLE TERMINALS SWITCH PANEL INSTALLATION CONNECTING TO THE TRACK ROCKER FUSE/RELAY CENTER (PAINLESS #58100) SWITCH WIRING DOUBLING SWITCH CONTROL WIRES ECM CONNECTION PAINLESS PERFORMANCE LIMITED WARRANTY AND RETURN POLICY... -
Page 5: Contents Of The Painless Kit
Refer to the Contents Figure (below) to take inventory. See that you have everything you’re intended to have in this kit. If you find that anything is missing or damaged, please contact the dealer where you obtained the kit or Painless Performance at (800) 423-9696. -
Page 6: Tools Needed
Painless offers “Roll-Over Crimpers,” such as those seen to the right, under Painless part #70900. A good set of wire strippers is required to strip wire properly. This style of wire stripper is ideal for this harness install because of its ability to properly strip wire gauges 10 thru 20. -
Page 7: Installing Factory Style Terminals
INSTALLING FACTORY STYLE TERMINALS In the parts kit, you will see uninsulated female terminals. These terminals are for 10-pin connector shell included in the Track Rocker Fuse/Relay Center parts kit, and require roll over crimpers. Strip about ∕ ” of insulation off of the wire. -
Page 8: Switch Panel Installation
58107 4 Switch Panel 4.84” x 1.72” Step 2: For easier installation, Painless recommends removing the dash panel, or other surface, on which you’re mounting the Track Rocker Switch Panel. On some applications, this may not be possible. Therefore, be careful to pick a location that is deep... - Page 9 Step 3: Use the templates included with this kit to create the appropriately sized hole for your switch panel. To do this, cut out the pattern, tape it to your location, and trace it onto your mounting surface. Step 4: Then, use your cutting tool to make the appropriately sized hole.
- Page 10 Step 5: Before mounting the Track Rocker Switch Panel, you may wish to loom the Switch Panel Wires. We recommend Painless ½” PowerBraid (P/N: 70902). Run the loom over the wire, and secure the end of the loom with a zip-tie. Note: It isn’t necessary to loom the entire wiring harness as you will cut these wires to length later.
- Page 11 Step 7: Put the Switch Panel in place on the mounting surface, and use a sharpie to mark your drill points. Step 8: Remove the Switch Panel and use a ∕ ” or #7 drill bit to create the (4) mounting holes.
- Page 12 Step 9: Put Track Rocker Switch Panel back in place and secure it to the mounting surface using (4) #10 lock washers, (4) #10 flat washers, (4) 10 – 32 hex nut, and (4) 10 – 32 x 1” button head screws.
-
Page 13: Connecting To The Track Rocker Fuse/Relay Center
CONNECTING TO THE TRACK ROCKER FUSE/RELAY CENTER (PAINLESS #58100) Step 10: Route the Switch Panel Wires to the Switch Control Wires coming from your Track Rocker Fuse/Relay Center (Painless #58100). A 10-pin, male connector housing was provided in the Fuse/ Relay Center’s parts kit. - Page 14 Step 13: Strip each of the Switch Panel Wires ∕ ”, and install a female pin terminal from the parts kit onto the end of each wire. See page 3 for detailed instructions on how to properly crimp these terminals. We recommend Painless #70900 Roll-Over Crimpers.
- Page 15 Step 14: Locate the 10-pin connector housing included in the Fuse/Relay Center’s parts kit. Note the locating tab for orientation. Step 15: Insert the newly pinned wires into the 10-pin connector housing. Make sure, while inserting the pins, that once connected the wire color matches the one across from it.
- Page 16 Step 16: Once completed, the connector should appear as it does to the left & below. Step 17: Link the two connectors and join the wiring harness from the Fuse/Relay Center to the Switch Panel. Use zip-ties to secure the wires up under the dash and out of the way.
-
Page 17: Switch Wiring
SWITCH WIRING The lighted rocker switches included in your kit are wired as shown in the diagram below. This kit also contains an optional Momentary On Switch for various applications such as a starter, nitrous purge, or fuel pump prime. - Page 18 Step 18: To replace a switch with the Momentary On Switch, remove the power, output, and ground wires from the switch you are replacing. Then, locate the tabs located at the top and bottom of the switch. Step 19: These tabs lock the switch in place. To remove the switch, squeeze the tabs in and slide it out of the bracket.
-
Page 19: Doubling Switch Control Wires
DOUBLING SWITCH CONTROL WIRES The Trail Rocker Fuse/Relay Center is capable of supporting 8 different accessories. Those with 4 & 6 Switch Panels may wish to control multiple accessories with a single switch in order to utilize all 8 relays. Steps 21 & 22 are optional and only for those who wish to control multiple functions for one switch. -
Page 20: Ecm Connection
ECM CONNECTION In some race applications, you may want to have components controlled with either a toggle or rocker switch AND an aftermarket ECM (Engine Control Module). If this is the case, the Track Rocker is designed to allow BOTH a grounding switch and an aftermarket ECM to ground the 85(-) terminal on the coil inside of the relay. - Page 21 Step 23: Refer to your ECM’s wiring diagram and locate the appropriate output for the component you wish to tie into the Track Rocker System. Step 24: Then, splice the ECM Output wire into the Switch Control wire of the switch you wish to use. See page 9 for the wire color chart.
- Page 23 Chassis harnesses, fuel injection harnesses, and Track Rocker units are covered under a lifetime warranty. All other products manufactured and/or sold by Painless Performance are warranted to the original purchaser to be free from defects in material and workmanship under normal use. Painless Performance will repair or replace defective products without charge during the first 12 months from the purchase date.
