Summary of Contents for Watch Water Proxima One
- Page 1 User Guide Version 1.0 English...
-
Page 2: Table Of Contents
All technical information, drafts, etc. are liable to law of copyright protection. © Copyright 2016, Watch Water GmbH. Printed in Germany. All rights reserved by Watch Water GmbH. - Page 3 Certification Certified Quality All Watch Water GmbH product used in this project is certified as per NSF Drinking Water Standards. System Warranty Restriction of warranty We reserve the right to change the contents of the documentation without notice. Watch Water...
-
Page 4: Introduction
1. Introduction We would like to thank you for having acquired the Proxima system. We are convinced that this product will give you satisfaction as it has been manufactured with extreme care. The Proxima system is delivered in a box and includes a by-pass valve. Please inspect carefully your device in presence of deliverymen to be sure it has not been damaged during transportation. -
Page 5: General Advice On The Installation
2. General advice on the installation Pressure A minimum pressure of 1.8 bar is needed to allow the valve to regenerate properly. Please do not operate over 8 bar. If this is the case, use a pressure reducer upstream of your installation. Power connection Be sure that power cannot be switched off accidentally at a wall switch. -
Page 6: System Programming
3. System Programming 3.1 Buttons for the end users Display: day, remaining m³ or days until the next regeneration. Button Functions: SET CLOCK • Setting the time "Replaces" and saves the changes in memory REGEN • turns on / off regeneration •... -
Page 7: Installation Instructions- Display Customer Level
3.2 Installation Instructions- Display Customer level Time of day Time display- „REGEN TODAY“ will alternate with current header if regeneration is expected today. * Water meter detects water flow. Push to go to the next parameter. Remaining capacity Remaining capacity Display- Each push on button decrease capacity by 0.01 M Push to go to the next parameter. -
Page 8: Setting Time Of Day
3.3 Setting Time of Day The user can also set the time of day. Time of day should only need to be set after power outages lasting more than 24 hours, if the battery has been depleted and a power outage occurs or when daylight saving time begins or ends. -
Page 9: Proxima System Cycle Sequence
3.4 Proxima System Cycle Sequence Proxima System instructions allows the end user to set the order of the cycle. The Proxima System Setup allows the end-user to set how long cycles will last. The end user may choose any cycle order from available number of cycle. - Page 10 Step 4- Press until BACKWASH appears. Press to go to Step 5. Press to return to previous step. www.watchwater.de...
- Page 11 3.5 Proxima system setup In Proxima System Setup the Watch control valve chooses the time for the cycles selected in Watch Cycle Sequence and specifies other operating parameters for the system. The upper and lower limits of the allowable values for the cycles are as follows: Step 1–...
- Page 12 Step 4– Select the time for the second cycle (which in this example is FILL) using .Press to go to Step 5. Press to return to previous step. Step 5– Select the time for the third cycle (which in this example is DRAW) using .Press to go to Step 6.
-
Page 13: Time Control Regeneration Setup
3.6 Time control regeneration setup STEP 1 - Press simultaneously for 3 seconds. STEP 2 – Day Override: When volume capacity is set to oFF, sets the number of days between regenerations. When volume capacity is set to AUTO or to a number, sets the maximum number of days between regenerations. - Page 14 STEP 4 – Next Regeneration Time (minutes): Set the minutes of day for regeneration using . This display will not be shown if “on 0” is selected in Set Regeneration Time Option in Watch Proxima System Setup. Press to exit Installer Display Settings. Press to return to previous step.
-
Page 15: How To Setup Proxima System
4. How to setup Proxima System When programming Proxima System choose from the different options while using . To select a specific option press to save it and continue to the next Step. allows you to go back and access the recent Step Setting time of day Step 1 „... - Page 16 By default Proxima System Setup This system set up can be change depending upon the real time situation. Step 1 „->“ & „-“ Step 2 Select FILTERING Select 15min (BACKWASH) Step 3 Select 10l (FILL) Step 4 Step 5 Select 1min (DRAWN time) Step 6 Select 30min (BACKWASH) Step 7...
