Summary of Contents for MadgeTech DHS
- Page 1 Product User Guide DHS Data Logging System Red 485 Dark Blue Pantone 289 Light Blue 58% of Pantone 289 DHS Data Logging System Dry Heat Sterilization Data Logging System To view the full MadgeTech product line, visit our website at www.madgetech.com.
- Page 2 DHS Data Logging System Product Overview The DHS Data Logging System for Dry Heat Sterilization is an all in one depyrogenation solution that comes equipped with: • HiTemp140-M12, High Temperature Data Logger • 36 inch Glass Braided RTD depyrogenation probe with M12 connector and flat probe tip •...
- Page 3 Product User Guide Removing the Data Logger from the Thermal Barrier 1. Unscrew the lid of the thermal barrier. 2. Slide out the data logger and lid from the barrier body. 4. Slide the probe of the data logger out 3.
- Page 4 Prices and specifications subject to change. See MadgeTech’s terms and conditions at www.madgetech.com To send devices to MadgeTech for calibration, service or repair, please use the MadgeTech RMA Process by visiting www.madgetech.com, then under the services tab, select RMA Process.
- Page 5 Product User Guide General Specifications Temperature Sensor 36 inch Glass Braided RTD depyrogenation probe Temperature Resolution 0.0001 Ω, 0.01 °C (0.02 °F) Temperature Accuracy ±1.2 °C (-200 °C to +400 °C) Probe Measurement Range -200 °C to +400 °C Connector Type M12 Female, 4 Pin Reading Rate 4 readings per second up to 1 reading every 24 hours...
- Page 6 Not Rated Barrier Materials 316 Stainless Steel, PTFE, Silicone Enclosure Dimensions 1.75 in OD x 9.6 in L (44.45 mm OD x 243.8 mm L) Weight 3.0 lb (1350 g) Specifications subject to change. See MadgeTech’s terms and conditions at www.madgetech.com...
- Page 7 Product User Guide Time vs. Temperature Chart Ambient Maximum Exposure Temperature Time (air) -200 °C 128 minutes -180 °C 137 minutes -160 °C 148 minutes -140 °C 163 minutes -120 °C 183 minutes -100 °C 213 minutes -80 °C 263 minutes -60 °C 368 minutes -40 °C to +140 °C...
- Page 8 MadgeTech with a detailed description of your process, including temperatures, durations, ramp times and process media such as air, steam, oil or water. If MadgeTech is unable to definitively calculate the suitability of our product for your application, a test unit outfitted with a high temperature indicator can be provided.
