Dwyer Instruments DW-USB-1-HT series Specification And Operating Instructions

Model DW-USB-1-HT High Temperature USB Data Logger allows
users to monitor temperatures up to 257°F (125°C). The rigid, stainless
steel enclosure protects the sensor against corrosion, impact, and water
ingress. With the easy to install Windows
can be configured to work in many applications. Data can be
downloaded by plugging the data logger directly into a PC's USB port,
with no cable required. Downloaded data can then be graphed, printed,
or exported to other spreadsheet applications.
OPERATING INSTRUCTIONS
Battery Installation
Before using the data logger, you will need to insert the 3.6 V 2/3 AA high
temperature battery provided, following the instructions below:
1. Use a coin to turn the battery cover counter-clockwise.
2. Remove the battery cover.
3. Insert battery, taking notice of the indicated polarities.
4. Replace battery cover. Use a coin to turn the cover clockwise until
securely tightened.
DWYER INSTRUMENTS, INC.
P.O. BOX 373 • MICHIGAN CITY, INDIANA 46361, U.S.A.
Series DW-USB-1-HT High Temperature USB Data Logger
Specifications and Operating Instructions
based software, parameters
®
4-3/8
[111.13]
Ø25/32
[19.84]
SPECIFICATIONS
Temperature Range: -40 to 257°F (-40 to 125°C).
Temperature Accuracy: ±1°F (±0.5°C).
Temperature Resolution: 0.2°F (0.1°C).
Memory Size: 32,510 readings.
Sampling Mode: Continuous or stop on memory full.
Sampling Rate: Selectable from 1 sec to 12 hours.
Computer Requirements: Windows
Vista , and Windows 7; 32 or 64-bit operating systems.
® ®
Power Requirements: 3.6 V 2/3 AA lithium battery (included).
Battery Life: Approximately 1 to 3 years.
Housing: 316 SS.
Enclosure Rating: IP67/NEMA 4X.
Alarms: Programmable high/low.
Interface: USB port.
Weight: 4.6 oz (130.4 g).
Agency Approvals: CE, RoHS.
Windows and Windows Vista are registered trademarks of Microsoft Corporation.
® ®
Phone: 219/879-8000
Fax: 219/872-9057
DLR-DW-USB-1-HT
2000, Windows XP, Windows
® ®
