Diagnostic Cable Mounting Bracket
Bracket used to mount the diagnostic cable
assembly to the trailer.
Figure 2.10
ECU/Valve Assembly Mounting Bracket
Bracket used to remote mount the ECU/Valve
Assembly to the trailer frame.
Figure 2.11
Diagnostic Cable Assembly with Protective Cap
Diagnostic cable mounted to the bracket
with a protective cap on the SAE J1587
diagnostic connector.
Figure 2.12
1002081a
1002082a
1002083a
System Components
Diagnostic Cable Assembly with Diagnostic Tool
Diagnostic cable mounted to the bracket with a
diagnostic tool connected to the SAE J1587
diagnostic connector.
Protective dust cap included.
Figure 2.13
Tooth Wheel
A machined ring mounted to the
machined surface on the hub of each
ABS-monitored wheel.
Figure 2.14
Section 2
1002084a
1002085a
