Brainstorm Electronics SR-3 Operation Manual

Time code repair kit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
Page 18
Other Brainstorm Products
SR-15+ Time Code Distripalyzer
Combines 3 units in a single space 19" chassis: a time code analyzer,
a 1x5 Time code distributor (w/reshaping on all 5 outputs) and
a pilot tone stripper. The analyzer identifies time code format,
detects errors and monitors video sync and color field alignment. A
comprehensive report can be sent to a printer or computer via the
parallel and RS-232 ports.
SA-1 Time Code Analyzer
Same analyzer as the one found in the SR-15+, in a small portable
package (same as the SR-3). It operates on an external 6VDC sup-
ply and can be used with a battery pack.
SR-26 Dual Time Code Distributor / Reshaper
Cleans up time code and distributes it through 6 individually buffered
outputs. Can be used as 2 separate units: 1x4 (master) + 1x2 (slave)
or as a single 1x6 unit - Same reshaping circuitry as the SR-1 with
individual output level controls & switchable output rise times.
SR-1 Time Code Reshaper
Cleans up unreadable code by eliminating distortions and level fluc-
tuations. Low input threshold (better than -30db) - Reshapes in fast
forward and rewind modes - Balanced or unbalanced input and
output - Adjustable output level - Switchable output rise time (
/square wave).
EBU
SR-2 Frame rate counter
Same unit as the SR-1 with a 4 digit counter that reads the incoming
time codeʼs frame rate. Ideal to identify the codeʼs format and verify
itʼs stability - Very accurate counter (4 updates per second) also
shows potential problems such as wow and flutter or jitter.
TB-4 Communicator System (wireless talkback remote)
A high-performance infrared remote that allows the producer to acti-
vate the consoleʼs talkback from anywhere in the control room - 4
switchable talkback functions - Rechargeable transmitter - No aim-
ing necessary - Easy to install - Includes transmitter and receiver.
For more information on these products, contact your Brainstorm
Electronics dealer.
/
SMPTE
All rights reserved. No part of this publication may be reproduced in any
form without prior written permission by Brainstorm Electronics, Inc.
SR-3
TIME CODE REPAIR KIT
Operation Manual
Operation Manual
Manual written by Brainstorm Electronics, Inc.
© Brainstorm Electronics, Inc., 1999

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR-3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Brainstorm Electronics SR-3

  • Page 1 SA-1 Time Code Analyzer Same analyzer as the one found in the SR-15+, in a small portable package (same as the SR-3). It operates on an external 6VDC sup- TIME CODE REPAIR KIT ply and can be used with a battery pack.
  • Page 2 Time Code and User Bits. the incoming code. Format: 24/25/30D/30ND/Color In SET mode, increases the value of 8. Mode Switch: Selects the SR-3’s TC In: indicates signal present the selected parameter (+). operations mode: Repair / Generate. Video ø: indicates valid video reference at video input 2.

  • Page 3: Table Of Contents

    Introduction Appendix C: Error Messages Repair Mode: The SR-3 Time Code Repair Kit is a regenerator designed to repair bad time code. Itʼs three main functions are to repair drop outs, NO VIDEO Video is not present and “Video Sync” is on.

  • Page 4: Setting Up The Sr-3

    BI-PHASE MARK PHASE CORRECTION BIT BINARY GROUP FLAG BIT The SR-3 requires 6 to 9VDC @ 500mA with center pin The SR-3 requires 6 to 9VDC @ 500mA with center pin The SR-3 requires 6 to 9VDC @ 500mA with center pin...

  • Page 5: Modes Of Operation

    The “Mode” switch to the right of the display toggles Software version number between the 2 modes and the 2 ledʼs above the switch indi- When the SR-3 is first turned on, the reader displays the cates which mode is currently selected. software version number for a few seconds.

  • Page 6: Flywheel Time

    During a drop out, the SR-3 generates code at the same rate ever the source time code is synchronous with video, you it did just prior to the drop out. After the drop out, the SR-3 should feed the video reference into the SR-3 and activate slowly resyncs to the incoming code.

  • Page 7: Video Sync

    79 of time code lines If you donʼt have an empty track or the time to re-stripe your ONE TIME CODE FRAME (12:35:08:28) tape with repaired code, you can insert the SR-3 at the output Sync Word Sync Word of your time code track and repair “on the fly”.

  • Page 8: Locking The Regenerator To External Video

    It is adjustable from full off to +12db. This adjusted Locking the regenerator to external Video level remains constant regardless of input level fluctuations. When “Video Sync” is on, the SR-3 locks the regenerated Output Waveform code to the incoming video reference. This is recommended since video is a very stable reference.

  • Page 9: Bypassing The Regenerator

    When the SR-3 switches to Bypass, the Reader displays the SYNC VIDEO FORMAT RATE SOURCE incoming code. However, the SR-3 is a play speed reader and if 30ND Internal Xtal high speed code is running through the SR-3, the Reader wonʼt 30DF Internal Xtal display it.

  • Page 10: Generate Mode

    If the reader is on TC when entering the SET mode, you can To set the SR-3 to generate time code hit the “Mode” switch edit the start time and the format; if it is on UB, you can edit until the “Generate”...

  • Page 11: Scrolling Through The Preset Parameters

    SR-3 TIME CODE REPAIR KIT Operation Manual BRAINSTORM BRAINSTORM ELECTRONICS, INC. ELECTRONICS, INC. Distributed Exclusively by: ...Intelligent Solutions For The Recording Studio plus24 West Hollywood, CA - USA Tel: (323) 845-1155 • Fax: (323) 845-1170 Tel: (323) 845-1155 • Fax: (323) 845-1170...
