- Page 1 C H I T U M A A U S T R A L I A P T Y L T D ETRIKE-LI 24/20 OWNER MANUAL C H I T U M A A U S T R A L I A P T Y LT D 6 KLAUER ST SEAFORD VIC AUSTRALIA 3198 Phone: 1300 681 112...
- Page 2 Page 2 THANK YOU FOR CHOOSING OUR ELECTRIC ASSISTED TRICYCLE OUR E-TRIKE CAN BE OPERATED VERY EASILY.IT CAN BE OPERATED BY THE MOTOR ALONE OR BY PEDALING ALONE OR A COMBINATION OF BOTH AT THE SAME TIME.IN ORDER TO GIVE YOU A LONG AND SAFE US- AGE PLEASE READ THE INSTRUCTIONS BEFORE USING.
- Page 3 Page 3 YOUR TRICYCLE IS DESIGNED FOR USE ONLY ON PAVED ROADS OR PATHS (WHERE THE LAWS PERMIT) DO NOT USE OFF THESE SURFACES OPERATION PERFORM SAFTEY CHECKS AND ADJUST SEAT FOR COMFORTABLE RIDING THE ROCKER SWITCH ON THROTTLE HANDLE TURNS THE MOTOR ON OR OFF SQUEEZE LEFT HAND BRAKE AND ALIGHT TRIKE FROM SAME SIDE...
- Page 4 CHARGING Page 4 YOU MUST ONLY USE THE CHARGER THAT WE SUPPLY WITH TRICYCLE ONLY USE IN A DRY WELL VENTILATED ENVIROMENT . WITH THE LEAD UNPLUGGED FROM 240V POWER SUPPLY PLUG INTO POINT LOCATED ON RIGHTHAND SIDE OF BATTERY ..PLUG INTO STANDARD 240V HOUSE HOLD POWER SUPPLY AND SWITCH ON.YOU WILL SEE A RED LIGHT ON CHARGER ,THIS INDICATES THE UNIT IS ON AND CHARGING THE BATTERY.WHEN CHARGED LIGHT...
- Page 5 OPERATING INSTRUCTIONS FOR MOTOR ASSISTANCE After completing safety check insert key into battery and turn clockwise . Making sure tilt mechanism is in locked position alight tricycle and place both feet on pedals. Press the on/off switch on display (located left side handlebar).
- Page 6 SPECIFICATIONS Page 7 PERIODIC MAINTENANCE ITEM 500klms 1000klms 1500klms 2000klms 3000klms BRAKES ALL CABLES CHAIN TYRES FRONT FORKS PEDAL ASSYS ALL NUTS BOLTS FASTENERS ETC A = ADJUST L= LUBRICATE I = INSPECT FOR WEAR ,TIGHTNESS AND CONDITION PLEASE NOTE THE ABOVE MAINTENANCE IS A SUGGESTED MINIMUMN AND IS NOT IN PLACE OF DAILY SAFTEY CHECKS PRIOR TO RIDING FOR ADVICE ON BRAKE ADJUSTMENT CHECK WITH YOUR DEALER OR LOCAL BIKE SHOP...
