Vive DMD1026GRY User Manual

WHAT'S INCLUDED
• Vive Precision Oral Thermometer
• Storage Case
• User Manual

WARNING

• Read instructions thoroughly before using the
digital thermometer.
• Choking Hazard: Thermometer cap and battery may be
fatal if swallowed. Do not allow children to use this device
without adult supervision.
• Do not use thermometer in the ear. Designed use is for
oral, rectal and armpit (axilla) readings only.
• Do not place thermometer battery near extreme heat as
it may explode.
• Use of a probe cover may result in a 0.1°C (0.2° F)
discrepancy from actual temperature.
• It is recommended that the performance should be
checked every two years.
• Remove the battery from the device when not in
operation over long periods of time.
• The performance of the digital thermometer may be
degraded if one or more of the following occur:
a) Operation outside the stated temperature and
humidity range
b) Storage outside the stated temperature and
humidity range
c) Mechanical shock
d) Patient temperature is below ambient temperature
• Do not bend or drop digital thermometer.
It is not shockproof.
• Do not boil probe to disinfect.
• Do not store in direct sunlight or in areas of extreme heat.
• Do attempt to disassemble or repair thermometer. See
Battery Replacement to replace the battery. Do not place in
domestic trash. Recycle or dispose of as hazardous waste.
Battery contains mercury.
• Avoid strong electromagnetic interference such as
microwave ovens and cell phones.
• After each use, disinfect thermometer, especially in case
the device is used by more than one person.

HOW TO CHANGE BETWEEN CELSIUS AND FAHRENHEIT

Temperature readings are available in both Celsius and
Fahrenheit (°C/°F is displayed in the upper right corner
of the LCD screen). With the device turned off, press and
hold the On/Off button for approximately three seconds to
change the current settings.

OPERATING INSTRUCTIONS

Figure 1
Probe
1. Wipe the probe with isopropyl alcohol to disinfect.
2. Press the On/Off button next to the LCD display to turn
the device on. A tone will sound as the display shows '
. The display will then show the current temperature scale,
followed by the last temperature reading or Lo if no
reading was taken. The thermometer is now in
testing mode.
3. Position thermometer in the desired location (mouth,
rectum, armpit)
a.) Oral use: Place thermometer
probe under the tongue as
indicated by the check mark in
Figure 2. Close your mouth and
breathe evenly through the nose
to prevent the measurement from
being influenced by inhales/exhaled
air. Normal temperature range for
an oral reading is between 35.7°C
and 37.3°C (96.3°F and 99.1°F).
b.) Rectal use: Lubricate silver probe tip with petroleum
jelly for easy insertion. Gently insert sensor approximately
1 cm (less than 1/2") into the rectum. Normal temperature
range for a rectal reading is between 36.2°C and 37.7°C
(97.2°F and 99.9°F).
c.) Armpit use: Wipe armpit dry. Place probe in the armpit
and keep arm firmly pressed at side. From a medical
viewpoint, this method will always provide inaccurate
readings, and should not be used in precise readings
are required. Normal temperature range for an axilla
reading is between 35.2°C and 36.7°C (95.4°F and 98.1°F).
LCD
ON/OFF Button
'
E
,
Figure 2
