Smart Vision SMC-A130SHR30C User Manual

Vandalproof ir dome camera

Advertisement

S p e c i f i c a t i o n
Model
SMC-A130SHR30C
Pick up Element
1/3" Aptina 1.3MP CMOS Sensor
Effective Picture
1280 X960
Elements (H×V)
Resolution
960P
0.001 Lux/F1.2
Minimum Illumination
S/N Ratio
More than 50dB
Synchronous System
Internal, Negative sync.
IR Distance
30 Meters (with
5 X36PCS Infrared LED)
Ф
IR Power On
Photodiode AUTO Control
Video Output
C V I
Functions
WDR,3DNR,UTC
Power/Current
DC12V(+/-10%)/700mA
Lens
2.8-12mm Manual Zoom Lens
IP Rating
Dimension (mm)
Φ131 x 93(H)
Weight (g)
800
Operating Tempera-
-10~+50
RH95% MAX
ture
A c c e s s o r i e s l i s t
Name
Camera
User Guide
/
Notes
Number
:
Do not attempt to disassemble the camera. If the camera
1
can not work, please contact local franchiser or our company.
1
CCTV Camera
Vandalproof IR Dome Camera
Thank you for using our product.
Before providing power for the camera, please read
this manual carefully before use.
We adopt the latest technical of sensor and driver.
It owns the characters of high definition and stability,
strong anti-jamming, rich and real color. Fixing and
using this model are convenient too. It is very good
for you to apply to your CCTV system.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMC-A130SHR30C and is the answer not in the manual?

Questions and answers

Summary of Contents for Smart Vision SMC-A130SHR30C

  • Page 1 S p e c i f i c a t i o n CCTV Camera Model SMC-A130SHR30C Pick up Element 1/3" Aptina 1.3MP CMOS Sensor Effective Picture 1280 X960 Elements (H×V) Resolution 960P Vandalproof IR Dome Camera 0.001 Lux/F1.2 Minimum Illumination...
  • Page 2 M a i n F e a t u r e s D e v i c e c o n n e c t i o n C o m m o n P r o b l e m s a n d T r o u b l e s h o o t i n g >...
