Summary of Contents for Maxi Comfort Oasis
- Page 1 U S E R M A N U A L PR OD U CT COD E RR019 5 8...
-
Page 2: Table Of Contents
CONTENTS LABEL INFORMATION SAFETY GUIDELINES GENERAL GUIDELINES MODIFICATIONS WEIGHT LIMITATIONS HAZARDS EMI/RFI DELIVERY TRANSPORT COMPONENTS ASSEMBLY OPERATION TROUBLESHOOTING CARE & MAINTENANCE SPECIFICATIONS WARRANTY PAGE 2... -
Page 3: Label Information
LABEL INFORMATION PRODUCT SAFETY SYMBOLS The symbols below represent labels used on the product to identify warnings, mandatory actions and prohibited actions. It is very important for you to read and understand these symbols completely. Do not remove these labels from your product. -
Page 4: Safety Guidelines
SAFETY GUIDELINES Congratulations on purchasing your MaxiComfort Rise Recliner Chair. The product you have purchased combines state-of-the-art components with safety, comfort and styling in mind. We are confident the design features will provide you with the conveniences you expect during your daily activities. Understanding how to safely operate and care for this product should bring you years of trouble-free operation and service. -
Page 5: General Guidelines
GENERAL GUIDELINES Your lift chair is a state-of-the-art life-enhancement device designed to increase mobility. Please be aware that the final selection and purchasing decision regarding the type of lift chair to be used is the responsibility of you, the lift chair user, if capable of making such a decision, and/or your healthcare professional (i.e., medical doctor, allied health professional, therapist, etc.). -
Page 6: Emi/Rfi
WARNING! Do not place objects or appendages in the path of moving parts. STORAGE AND OPERATION TEMPERATURES Transportation or storage: -75°C/-104°F to 70°C/158°F Operation: 10°C/50°F to 40°C/104°F ELECTROMAGNETIC AND RADIO FREQUENCY INTERFERENCE (EMI/RFI) Laboratory tests have shown that electromagnetic and radio frequency waves can have an adverse effect on the performance of electrically-powered devices, such as lift chairs. -
Page 7: Delivery
The addition of accessories or components to the lift chair can increase the susceptibility of the chair to EMI. Do not modify your lift chair in any way. Your lift chair itself can disturb the performance of other electrical devices located nearby, such as alarm systems. -
Page 8: Components
COMPONENTS This section describes the features of your lift chair. Carefully review the function and location of each item described and note that the illustrations and option locations shown in this manual may not reflect the type of lift chair that you own. Hand Control Power Lead External... - Page 9 ELECTRICAL COMPONENTS Your MaxiComfort Lift Chair is equipped with a low voltage DC motor system that reduces the standard household alternating current of 90V AC - 264V AC to direct current (24/39V DC). The electrical components include the external transformer, batteries and hand control.
-
Page 10: Assembly
ASSEMBLY Your lift chair may require some assembly before initial use. It may also require disassembly to make servicing the chair more convenient. LIFT CHAIR SET-UP This model will arrive in the knock-down position (Fig. 2) Fig. 2 Knock-Down (KD) Position FOLLOW THESE STEPS TO ASSEMBLE THE LIFT CHAIR Correct Incorrect... - Page 11 “Click” Fig. 5 Fig. 6 3 Push firmly on the top of the 4 Attach the chair-back to the hook chair-back to lock into position. Listen and loop flaps on the bottom of the for a click on each side to ensure the chair base.
- Page 12 LIFT CHAIR PLACEMENT Your lift chair should be placed near a standard electrical outlet on dry, level ground where there is ample room to allow for proper operation. It is recommended that you have the assistance of an attendant when positioning the lift chair to avoid the possibility of injury when lifting.
- Page 13 BATTERY INSTALLATION Your lift chair should be placed near a standard electrical outlet on dry, level ground where there is ample room to allow for proper operation. It is recommended that you have the assistance of an attendant when positioning the lift chair to avoid the possibility of injury when lifting.
-
Page 14: Operation
OPERATION SAFE OPERATING PRECAUTIONS There are certain precautions that should be taken during the operation of your lift chair. Read and follow these precautions carefully in order to ensure safe lift chair operation and to prevent injury and/or product damage. •... - Page 15 HAND CONTROL OPERATION The hand control is equipped with switches that control the movement of the chair-back, chair base and footrest. Do not lean on or apply downward force to the chair-back when the lift chair is in the fully reclined position. Doing so could cause the lift chair to tip, resulting in personal injury and/or product damage Do not use the footrest as a seat, or for purposes outside its intended use.
- Page 16 OPERATION CONT. FOLLOW THESE STEPS TO SIT IN YOUR LIFT CHAIR 1. Ensure the chair back is UP and footrest is DOWN engaging the Chair Back UP and Footrest DOWN positions. 2. Engage and hold the up/down switch in the UP position to raise your lift chair to the standing position.
- Page 17 FOLLOW THESE STEPS TO STAND UP FROM YOUR LIFT CHAIR FROM THE SEATED POSITION 1. Ensure the chair back is UP and footrest is DOWN by engaging the chair back UP and footrest DOWN position. 2. Engage and hold the up/down switch in the UP position to raise your lift chair to the standing position.
-
Page 18: Troubleshooting
TROUBLESHOOTING Your MaxiComfort Lift Chair is a state-of-the-art product designed to enhance your mobility. Your lift chair should bring you years of trouble-free service, however, it may require occasional troubleshooting. The following troubleshooting tips and FAQs should summarise what you need to know about your lift chair. - Page 19 What if my lift chair stops during a lifting cycle? • Your lift chair is equipped with an internal thermal shut-off switch located inside the external transformer that prevents the motor control box from overheating. If the thermal shut-off activates, allow the lift chair to remain in a stationary position for 10 minutes to allow the motor to cool, then resume normal operation.
-
Page 20: Care & Maintenance
CARE & MAINTENANCE Your MaxiComfort Lift Chair will require routine maintenance checks. You can perform some of these checks, but others may require assistance from an authorised MaxiComfort Dealer. By following the maintenance checks in this section as scheduled, you can help ensure your lift chair gives you years of trouble-free operation. - Page 21 ELECTRONICS CARE • Inspect all wiring harnesses to make sure they are not damaged or frayed. • If damage is present, unplug the lift chair and contact your authorised MaxiComfort Dealer for service. • Keep all electronics free from moisture and temperature extremes. •...
-
Page 22: Specifications
SPECIFICATIONS MaxiComfort Oasis Factory Model Name RR01958 Factory Model Number inch seat width 19.5 seat depth 20.67 18.33 seat height 35.88 chair width 23.01 backrest height chair height(sitting) 41.34 54.6 chair height(lifted) 24.18 armrest height(sitting) 63.57 chair length(reclined) 180kg Max user weight... -
Page 23: Warranty
WARRANTY QUALITY / WARRANTY DECLARATION Products are to be fit for purpose and of excellent quality and performance. For valid warranty claims MaxiComfort will, at their discretion, replace / repair / refund items mutually agreed to be defective. The lift chair’s warranty is as follows: •...
