DZK -ZTS-3 Manual

WIRELESS THERMOSTAT
Graphic interface with low-energy e-ink screen and capacitive buttons for
controlling zones in DZK systems. Wireless communications. Powered by battery
button CR2450. Finished in steel and glass.

Functionalities:

•
Available languages: English, French and Spanish.
•
Control of set point temperature. Displayed in 1ºF/0.5ºC increments.
•
Configurable set point range for Cooling and Heating.
•
Auto changeover mode can automatically change to cool/heat mode at set
point ±1ºF/0.5ºC (can be configured from 0 to 7ºF using field settings) with a
guard timer of 15, 30, 60 or 90 minutes.
• Room temperature and relative humidity measurement of the zone.
• Timer function.
Phone: (855) 770-5678 | http://www.daikinac.com
DZK-ZTS-3
Rev. 1.00
W
H

TECHNICAL SPECS

Type of power supply
Useful life of battery
Stand-by consumption
Communication frequency
Maximum power
Total wireless reach
(Control board to thermostat)
Operating humidity range
10-2016
Set-point temperature range
Reading accuracy
Relative humidity
Dimensions (WxHxD)
D
Power supply and consumption
Vdc
V max 3.3 V
I max 30 mA
Battery CR2450
2 years
0.01mW
Connection and communications
915 MHz
0 dBm
130 ft (40 m) in clear line of sight
Operating temperatures
Storage -4 to 158ºF (-20 to 70 ºC)
Operation 32 to 122ºF (0 to 50ºC)
5 to 90% (non-condensing)
59 to 86ºF (15 to 30ºC)
±1ºF (±0.5 ºC)
Display accuracy ±1ºF (±0.5 ºC)
±4 %
Mechanical aspects
Assembly Surface through support
Protection class IP 20
Type of probe
Airzone_NTC_10K
Weight (Mass) 0.40 lb (180 g)
3.62x3.62x0.62 inch (92x 92x15.85 mm)
4008862
