Mobile Media Center for Flat-Screen TV -
One-Touch Height Adjustment
STNDMTV70
FR: Guide de l'utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l'uso - it.startech.com
For the latest information, technical specifications, and support for
this product, please visit www.StarTech.com/STNDMTV70.
Manual Revision: 09/05/2018
*actual product may vary from photos

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STNDMTV70 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for StarTech.com STNDMTV70

  • Page 1 Mobile Media Center for Flat-Screen TV - One-Touch Height Adjustment STNDMTV70 *actual product may vary from photos FR: Guide de l’utilisateur - fr.startech.com DE: Bedienungsanleitung - de.startech.com ES: Guía del usuario - es.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com IT: Guida per l’uso - it.startech.com...
  • Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
  • Page 3 te gebruiken. Warning statements Dit product is alleen bedoeld voor binnengebruik en mag niet buiten worden gebruikt. Make sure that you assemble this product according to the instructions. Draai de schroeven niet te strak vast wanneer u dit product in elkaar zet. Als u weerstand voelt tijdens het vastdraaien van de schroeven, stop dan.
  • Page 4 Durante l’assemblaggio del prodotto, non stringere troppo le viti. Se si incontra resistenza mentre si Perigo de energia armazenada! A coluna neste produto contém um mecanismo de elevação que pode stringono le viti, interrompere l’operazione. mover rapidamente quando remover o equipamento descarregado. Antes de remover equipamento ou fazer ajustes na tensão de elevação, mover o ecrã...
  • Page 5: Table Of Contents

    Table of Contents Warnings ..............................i Introduction ....................1 Product dimensions ..........................1 Product diagram ............................2 Technical specifications .......................... 3 Package contents ............................4 Requirements ............................. 10 Asssembly....................11 Assemble the base ............................ 11 Adjust the height of the casters ......................12 Attach the column to the base ......................
  • Page 6 Adjusting the STNDMTV70 ..............39 Change the orientation of the TV ......................39 Adjust the angle of the TV ........................40 Adjust the height of the multimedia shelf ..................41 Adjust the height of the camera shelf ....................42 Lock the vertical position of the TV ....................43 Technical support ...................44...
  • Page 7: Introduction

    Introduction Product dimensions Support plate rotation: 0° to +90° TV tilt: +5° to -12° Instruction manual...
  • Page 8: Product Diagram

    Product diagram Camera shelf Connecting plate Support plate Adapter bracket Crossbar Column Multimedia shelf Right leg Plastic cover Pedal lock Base Left leg Caster Instruction manual...
  • Page 9: Technical Specifications

    Technical specifications Unless otherwise indicated, the technical specifications in the table below apply to the Type of measurement Measurement 200x200 300x300 VESA mounting hole pattern on the TV mount 400x200 400x400 600x400 40 kg Weight capacity of TV mount (88 lb.) 8 to 25 kg (18 to 55 lb.) Note: If you exceed the lift Lift capacity of TV mount...
  • Page 10: Package Contents

    Package contents Base Left leg Qty: One Qty: One Right leg Left base cover Qty: One Qty: One Right base cover Left support bracket Qty: One Qty: One Instruction manual...
  • Page 11 Right support bracket Column cover Qty: One Qty: One Column Multimedia shelf Qty: One Qty: One Camera shelf Connecting plate Qty: One Qty: One Instruction manual...
  • Page 12 Plastic cover Cable clips Qty: One Qty: Three Adapter brackets Crossbars Qty: Two Qty: Two End caps Support plate Qty: Four Qty: One Instruction manual...
  • Page 13 Wrench Hook-and-loop ties Qty: One Qty: Two M6x16 mm screws M6x25 mm screws Qty: Four Qty: Two Support plate nuts Countersunk screws Qty: Two Qty: Three Instruction manual...
  • Page 14 M4x6 mm screws M6x8 mm screws Qty: Two Qty: Six M6x14 mm screws M8x25 mm screws Qty: Ten Qty: Four Washers Shelf spacers Qty: Four Qty: Four Instruction manual...
  • Page 15 Hex key Caster wrench Qty: One Qty: One M5x14 mm screws M6x14 mm screws Qty: Four Qty: Four M6x30 mm screws M8x30 mm screws Qty: Four Qty: Four Instruction manual...
  • Page 16: Requirements

    Qty: Eight Instruction manual Qty: One Requirements • A TV that is compatible with one of the VESA mounting hole patterns STNDMTV70 supports • A Phillips™ type screwdriver Requirements are subject to change. For the latest requirements, please visit www.StarTech.com/STNDMTV70.
  • Page 17: Asssembly

    Asssembly Warning! Assembling this product requires multiple people. DO NOT attempt to assemble this product and install equipment without assistance. Assemble the base 1. Insert the base into the left leg, aligning the holes in the base with the holes in the left leg.
  • Page 18: Adjust The Height Of The Casters

    Adjust the height of the casters You can adjust the height of each of the four casters so that the casters are balanced and the assembly doesn’t rock. 1. Use the caster wrench to loosen the nuts above the casters. 2.
  • Page 19: Attach The Column To The Base

    Attach the column to the base 1. Snap the column cover onto the top of the column. (figure 3) figure 3 Column cover Column 2. Press the pedal locks down on each of the casters to lock them in place and prevent the legs from moving as you attach the column.
  • Page 20 3. Line up the holes in the bottom of the column with the holes in the base. 4. While another person holds the column upright, insert the four M8x25 mm screws through the base and into the column. 5. Use the hex key to tighten the M8x25 mm screws. (figure 5) figure 5 Column M8x25 mm screw...
  • Page 21 6. Snap the left base cover and the right base cover onto the base and legs. (figure 6) figure 6 Right base cover Left base cover Base Instruction manual...
  • Page 22: Assemble The Tv Mount

    Assemble the TV mount 1. Slide the crossbars through the top and bottom openings in the support plate. (figure 7) figure 7 Crossbar Support plate 2. Position the crossbars so that they are centered on the support plate and the holes on the crossbars are aligned with the holes in the support plate.
  • Page 23: Attach The Support Plate To The Column

    5. Snap an end cap onto each of the four ends of the crossbars. (figure 9) figure 9 Crossbar End cap Attach the support plate to the column 1. Lift up the support plate and hook the top of the support plate onto the protrusion and the studs on the column.
  • Page 24 2. Place the support plate nuts over the studs on the column and use your fingers to tighten the support plate nuts. 3. Use the wrench to finish tightening the support plate nuts. (figure 11) figure 11 Support plate nut Wrench Column Instruction manual...
  • Page 25: Move The Support Plate To The Lowest Position

    Move the support plate to the lowest position When the spring-loaded pin is positioned in one of the holes in the side of the spool at the bottom of the column, the vertical position of the TV is locked and you can’t move the TV up or down the column.
  • Page 26 1. To unlock the vertical position of the support plate, at the bottom of the column, next to the spool, pull the pin out and turn it to the unlocked position. (figure 13) figure 13 Column Spool 2. Pull the support plate and adapter brackets down until they are at the bottom of the column.
  • Page 27: Attach The Adapter Brackets To A Flush Mounting Surface

    Attach the adapter brackets to a flush mounting surface To accommodate different TV designs, the STNDMTV70 comes with five sets of screws of different lengths and diameters, TV washers with two hole sizes, and two sizes of spacers. Warning! Make sure that the weight of the TV doesn’t exceed the weight capacity of this product.
  • Page 28 figure 14 M5x14 mm screw M6x14 mm screw TV washer Adapter bracket Top of TV Instruction manual...
  • Page 29: Attach The Adapter Brackets To A Recessed Mounting Surface

    Attach the adapter brackets to a recessed mounting surface To accommodate different TV designs, the STNDMTV70 comes with five sets of screws of different lengths and diameters, TV washers with two hole sizes, and two sizes of spacers. Warning! Make sure that the weight of the TV doesn’t exceed the weight capacity of this product.
  • Page 30 M8x50 mm combined with 1 small spacer 2 small spacers 2 large spacers 2 large spacers 2 large spacers 3. Position the adapter brackets so that the hooks on the adapter brackets are pointed towards the bottom of the TV and are aligned with the mounting holes on the back of the TV.
  • Page 31 figure 15 M6x30 mm screw M8x30 mm screw M8x50 mm screw TV washer Spacers Adapter bracket Top of TV Instruction manual...
  • Page 32: Attach The Tv To The Column

    Attach the TV to the column Warning! Attaching the TV requires multiple people. Do not attempt to complete this task by yourself. Warning! Make sure that you move the support plate to the lowest position on the column before you attach the TV. For more information, see the “Move the support plate to the lowest position”...
  • Page 33 3. Center the TV on the crossbars, and insert four M6x14 mm screws through the crossbars and into the adapter brackets. (figure 17) 4. Use a Phillips type screwdriver to tighten the M6x14 mm screws. figure 17 Adapter bracket Crossbar M6x14 mm screw Instruction manual...
  • Page 34 5. To secure the TV in the landscape position, insert two of the M6x8 mm screws into the support plate and use a Phillips type screwdriver to tighten the screws. (figure 18) To move the TV into portrait orientation, see the “Change the orientation of the TV” section.
  • Page 35: Counterbalance The Weight Of The Tv

    Counterbalance the weight of the TV When you add a TV to the STNDMTV70, you need to adjust the lift capacity of the TV cart to support the weight of the TV. If the lift capacity of the STNDMTV70 isn’t set correctly, when you let go of the TV, it could free fall down the column or move up the column unaided, resulting in damage to the TV or personal injury.
  • Page 36: Attach The Plastic Cover

    Warning! The degree of the lift strength that you set the STNDMTV70 to depends upon the weight of the TV. Every time that you take a TV off of the STNDMTV70 and add a different TV, you must counterbalance the weight of the TV again.
  • Page 37 2. Place the two halves of the plastic cover around the spool and snap the two sides together. 3. Move the assembled plastic cover in towards the column and carefully hook the tabs on the top of the plastic cover into the slots on the column. 4.
  • Page 38: Attach The Cable Clips

    Attach the cable clips 1. Remove the backing from the cable clips. 2. Attach the cable clips along the column. 3. Route the cables down the column and through the cable clips. 4. Snap the cable clips closed. (figure 22) figure 22 Column Cable clip...
  • Page 39: Install The Multimedia Shelf

    Install the multimedia shelf 1. Place the shelf spacers over the projections on the underside of the multimedia shelf. 2. Position the right and left support brackets over the washers so that the holes are aligned and the scalloped edges of the adapter brackets are pointed towards the outside edges of the multimedia shelf.
  • Page 40 5. Turn the knob on the shelf bracket counterclockwise to loosen it. 6. Move the shelf bracket to the height that you want the multimedia shelf to be at, and turn the knob clockwise to tighten it. (figure 24) figure 24 Shelf bracket Knob Instruction manual...
  • Page 41 7. Hook the multimedia shelf over the screws in the shelf bracket and slide the multimedia shelf downwards. 8. Insert two M6x14 mm screws into the multimedia shelf and into the shelf bracket. 9. Use a Phillips type screwdriver to tighten all four of the M6x14 mm screws. (figure 25) figure 25 Multimedia shelf Shelf bracket...
  • Page 42: Attach The Camera Shelf

    Attach the camera shelf 1. Line up the holes on the camera shelf with the holes on the end of the connecting plate. 2. Insert the three countersunk screws through the top of the camera shelf and into the connecting plate. 3.
  • Page 43 6. Determine the height that you want the camera shelf to be at and line it up with the mounting slots on the back of the column. 7. Insert the two M6x25 mm screws through the connecting plate and into the column.
  • Page 44: Attach The Wrench

    Attach the wrench 1. Thread the two hook-and-loop ties through the hole in one of the support brackets under the multimedia shelf. 2. Hold the wrench against the support bracket and wrap the hook-and-loop ties around the wrench. (figure 29) figure 29 Multimedia shelf Wrench...
  • Page 45: Adjusting The Stndmtv70

    Adjusting the STNDMTV70 Change the orientation of the TV You can position the TV in either landscape or portrait orientation on the STNDMTV70. 1. To display the TV in portrait orientation, if present, remove the two M6x8 mm screws from the back of the support plate.
  • Page 46: Adjust The Angle Of The Tv

    Adjust the angle of the TV 1. Turn the knobs on either side of the support plate counterclockwise to loosen them. 2. Push or pull the top or bottom of the TV to adjust the angle of the TV. 3. Turn the knobs on either side of the support plate clockwise to tighten them. (figure 31) figure 31 Knob...
  • Page 47: Adjust The Height Of The Multimedia Shelf

    Adjust the height of the multimedia shelf 1. Under the multimedia shelf, turn the knob counterclockwise. 2. Move the multimedia shelf to the desired height, and turn the knob clockwise to tighten it into place. (figure 32) figure 32 Knob Instruction manual...
  • Page 48: Adjust The Height Of The Camera Shelf

    Adjust the height of the camera shelf 1. Loosen the two M6x25 mm screws attaching the connecting plate to the column. 2. Move the connecting plate to the desired height, and use a Phillips type screwdriver to tighten the M6x25 mm screws into place. (figure 33) figure 33 Connecting plate Instruction manual...
  • Page 49: Lock The Vertical Position Of The Tv

    Lock the vertical position of the TV When the TV is at the height that you want it to be at, you should lock the vertical position of the TV to prevent the TV from moving up or down the column. Warning! Exercise caution when you pull the pin out of the spool and turn it to the unlocked position.
  • Page 50: Technical Support

    Limitation of liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
  • Page 51 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
