Summary of Contents for FPGA Solution FS -EXPLOR SP6-V2
- Page 1 FS -EXPLOR SP6-V2 VLSI Development Board User Manual Shop No. 401, Samruddhi Hight’s, Behind Katraj Dairy Pune-46 info@fpgasolution.com, Mobile: 9665889991 WWW.FPGASOLUTION.COM...
-
Page 2: Push Buttons
Key Features: Spartan6-XC6SLX9_TQ144FPGA Up to 102 user-I/O pins TQ-144 package Key components: USB-POWER Variable clock XC6SLX9_TQ144 OSCILLATOR – 12MHz XILINX USB-UART USB-JTAG FLASH – M25P40 USB Power On board USB Jtag FREE I/O-40 CLOCK-12MHz SPARTAN - 6 ... - Page 3 BOARD POWERING TheFS-EXPLOR-SP6-V2 board can work on USB power or external 5VDc supply. When JP2 jumper is placed in 2 & 3 power is used from USB connector. When JP2 jumper is placed in 1 & 2 power is used from external 5VDc supply LED’s and DIP Switches Interface has 16 individual bidirectional I/O’s.
- Page 4 LCD Interface The FS-EXPLOR-SP6-V2 board has 4 seven segment multiplexed with LCD, using JP12 & JP11 jumper When you want to use seven segments user can decided LCD is to be power on OR seven segment. connect jumper to J12 as shown below When you want to use LCD connect jumper to J11 as shown below Signal Switch...
- Page 5 Pushbuttons Interface The FS-EXPLOR-SP6-V2board has 4 individual pushbuttons for input purpose.The pushbuttons are read as 0 when pushed. They are read as 1 in normal ( unpressed) condition. Pushbuttons are labeled as SW1 TO SW4. Pin Assignment (UCF Location) for Pushbuttons: Signal XC6SLX9 Active...
- Page 6 ADC Interface The FS-EXPLOR-SP6-V2board includes anADC MCP3004. The ADC has 4 analog input channels. The channels are selected by setting the address pins of ADC. The analog input to all channels is given by external circuit through relimate pins. The other controlling signals of ADC are interfaced with FPGA board as shown in following figure.
- Page 7 DAC Interface FS-EXPLOR-SP6-V2board includes 8-bit channels, digital-to-analog converter (DACs)DAC084S085. DAC allows easy interface to most popular microprocessor buses and output ports. DAC works on 3.3V. The following figure shows the interfacing diagram of DAC with FPGA Board.VREF is connected to 3.3V, so analog voltage output rang of all channel is 0 to 3.3V. Pin Assignment (UCF Location) DAC084S085: Signal Name XC6SLX9...
- Page 8 USB Interface The FS-EXPLOR-SP6-V2board have USB interface using device FT2232HL from FTDI. This actsJtag and USB to UART converter so that Communication with FPGA can accomplish by USB port. Pin Assignment (UCF Location) for USB interface: Signal Name XC6SLX9 USB_Rx P102 USB_TX P104...
- Page 9 Clock Sources The FS-EXPLOR-SP6-V2supports clock input sources which are listed below. The board includes an on-board 12 MHz clock oscillator. Thisboard also has a variable clock frequency generator. You can very frequency by using PR1 pot, LED4 will show variable clock. Signal Name XC6SLX9 Clock 12Mhz...
-
Page 10: Free Input Output
FREE INPUT OUTPUT The FS-EXPLOR SP6-V2board has seven free input output connectors. Each connector have 8 input output pins, 3.3V Dc pin and GND pin. Signal XCS6LX9- Signal XCS6LX9- Name Name TQG144 TQG144 Name Name J3_1 P126 J5_1 J3_2 P127 J5_2 J3_3 P131... - Page 11 Signal XCS6LX9- Name TQG144 Name J9_1 J9_2 J9_3 J9_4 J9_5 J9_6 J9_7 J9_8 P100 J9_9 J9_10 +3.3V...
