Shenzhen HONY Optical FDT05 User Manual

Passive 3d cinema system turbo screen
Hide thumbs
Table of Contents

Advertisement

Quick Links

Enlarged version
Passive 3D Cinema System
TURBO SCREEN
Model No.: FDT05
User Manual
Address: 4th Floor, Jinlaiwang Science Park, No. 7, Jiayi Industril Zoon,
Guiyue Road, Guihuacun, Guanlan town, Baoan District, Shenzhen
Tel : +86-755-29045554
Fax :+86-755-29045524
SHENZHEN HONY OPTICAL CO., LTD
Website: www.hony3d.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FDT05 and is the answer not in the manual?

Questions and answers

Summary of Contents for Shenzhen HONY Optical FDT05

  • Page 1 Passive 3D Cinema System TURBO SCREEN Model No.: FDT05 User Manual Address: 4th Floor, Jinlaiwang Science Park, No. 7, Jiayi Industril Zoon, Guiyue Road, Guihuacun, Guanlan town, Baoan District, Shenzhen Tel : +86-755-29045554 Fax :+86-755-29045524 SHENZHEN HONY OPTICAL CO., LTD Website: www.hony3d.com...

  • Page 2: Table Of Contents

    Contents 1. System Overview..................1 2. System Features..................2 3. Requirements on Cinema Environment............2 4. Projector Setting..................2 5. 3D System Components................3 5.1 Optical Unit...................4 5.2 Bracket....................5 6. Installation of 3D System................6 6.1 Installing Pedestal Mount Components.............6 6.2 Installing the Motorized Bracket...............7 6.3 Installing Lifting Mechanism and Optical Unit..........8 7.

  • Page 3: System Overview

    1. System Overview 2. System Features Electrical Features Turbo Screen 3D cinema system is especially designed for the cinema application. In cooperation with high quality 3D glasses, the system Power Input: AC 100~240V 50/60 Hz provides stunning 3D images for small or medium size auditorium on Sync Input: GPIO (37PIN) or 3D interface (15PIN) screens up to 20m wide.

  • Page 4: D System Components

    5.1 Optical Unit 5. System components: Each Turbo Screen system includes following components: Optical Unit, Bracket, Power Adapter, Power cord Box, SYNC Cable, Motor Driving Signal Cable 282mm 96mm Optical Unit System Bracket Power cord Box Light Incident Window Light Exit Window Figure 5-1-1 Optical Unit Figure 5-1 System Components Optical Unit is composed of valuable optical elements.

  • Page 5: Bracket

    5.2 Bracket 6. System Installation Each Turbo Screen system has a bracket to match with the projector 6.1 Installing Pedestal Mount Components: adjust the pedestal . It can be used to adjust the Turbo Screen system's height, angle, height and length of pedestal mount components, and fix the components left and right as well as front and rear position to perfectly fit the space of onto the projector pedestal with fastener, as shown in Figure 6-1.

  • Page 6: Installing The Motorized Bracket

    6.2 Installing the Motorized Bracket 6.3 Installing Lifting Mechanism and Optical Unit Fix aluminum section (30*60*800mm) onto the pedestal mount Fix lifting mechanism onto the motorized bracket, and then install the components with L shape block, and then install the motorized bracket optical unit onto the lifting mechanism, as shown in Figure 6-3.

  • Page 7: System Connection

    7.2 LED Status Indicators 7. System Connection After the connection is completed, turn on the system and digital projector 7.1 Device Interface to play a 3D movie, check the cables are connected correctly by observing Optical Unit (MOTOR interface)------- Motorized Bracket（Motor driving signal interface） the LED status indicators on the front panel, as shown in Figure 7-2.

  • Page 8: Adjustment

    8.2 Height and Angle Fine Adjustment: 8. Adjustment Turn on the projector and load cross calibration pattern from the projector, 8.1 Centering Adjustment: briefly adjust position of up and down, left and right, center the position of Power on optical unit and the projector to play 3D movie, the optical unit the pattern on the light exit window, as shown in Figure 8-2.

  • Page 9: Image Adjustment

    Position projector lens focuses on the screen, fine adjust upper beam and 9. Image Adjustment lower beam position to coincide the cross calibration pattern align with Clear 3D imagery synthesis depends on the upper and lower beam image middle beam, when finish, adjust the size of middle beam image to center position and the middle beam image size.

  • Page 10: Cautions

    10. Cautions Remove screen protector from optical unit after installation. Use adhesive tape to seal the adjustment holes in the back of the system after installation to avoid the optical components get contaminated by dust. The surface of system should be cleaned periodically. If the surface becomes clogged by dust or the like, internal optical components may be contaminated.
