CONTENTS:
Page 1
Specifications
Page 2
Safety and Warning Information
Page 3-4
Operating Instructions
Page 5
Diagram
Page 6
Parts List
Page 7
Troubleshooting
Capacity
Length
Height
Width
Connector
Air Pressure
Weight
SPECIFICATIONS
10 Tons
14.56"
7.32"
6.61"
1/4" NPT
100-120 PSI
5.15 lbs
Page 1
10 Ton Open Body Air/Hydraulic Foot Pump
Model 805
OWNER'S MANUAL
Advertisement
Summary of Contents for AFF 805
- Page 1 Model 805 10 Ton Open Body Air/Hydraulic Foot Pump OWNER'S MANUAL CONTENTS: Page 1 Specifications Page 2 Safety and Warning Information Page 3-4 Operating Instructions Page 5 Diagram Page 6 Parts List Page 7 Troubleshooting SPECIFICATIONS Capacity 10 Tons Length 14.56"...
- Page 2 Loads may slip or fall and personal or property damage may result. • Immediately replace worn or damaged parts with genuine AFF parts. • To avoid personal injury keep hands and feet away from cylinder and work piece during operation.
-
Page 3: Operating Instructions
OPERATING INSTRUCTIONS BEFORE USING PUMP: • Check all system fitting and connections to be sure they are tight and leak free. • Check oil level in the reservoir before operating pump. TO OPERATE PUMP: • Remove the filler plug without hole and replace with the filler plug with hole. •... - Page 4 OPERATING INSTRUCTIONS Continued Pump with Single-Acting Cylinder • Position pump at higher elevation than cylinder. • Position cylinder with plunger end down (up if using pull cylinder). • Operate pump to fully extend the cylinder (retract if using a pull cylinder). •...
- Page 5 DIAGRAM Page 5...
-
Page 6: Parts List
PARTS LIST PART NUMBER DESCRIPTION PART NUMBER DESCRIPTION PCN-401A-01 Quick coupler-male PCN-401A-43 Release bar PCN-401A-02 Oil mist PCN-401A-RK Spring PCN-401A-03 Screw PCN-401A-RK O-ring PCN-401A-04 Lock washer PCN-401A-46 Release valve seat PCN-401A-05 Cover PCN-401A-47 PCN-401A-RK O-ring PCN-401A-RK O-ring PCN-401A-RK O-ring PCN-401A-RK Ball PCN-401A-08 Small piston... -
Page 7: Troubleshooting
● Leaking seals ● Locate leak(s) and have equipment serviced by an ● Internal leaking in pump authorized AFF repair depot. ● Cylinder does not retract, ● Pump reservoir is overfilled ● Drain oil level to fill mark retracts part way, or retracts ● Loose hydraulic coupler ● Check that all couplers are fully �ghtened more slowly than normal ● Air trapped in system ● Remove air according to the instruc�ons ● Cylinder retrac�on spring broken or ● Have cylinder serviced by an authorized AFF repair other cylinder damage depot Shop the largest selection of automotive tools in our online store.
