Roger Access Control System
Installation guide for
HRT82TS temperature sensor module
Firmware version: 1.0.8.23 or newer
Hardware version: 1.0
Document version: Rev. C
© 2016 ROGER sp. z o.o. sp.k. All rights reserved. This document is subject to the Terms of Use in their current version published at
the
www.roger.pl
website of the Roger sp. z o.o. sp.k. company (hereinafter referred to as ROGER).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HRT82TS and is the answer not in the manual?

Questions and answers

Summary of Contents for Roger HRT82TS

  • Page 1 Hardware version: 1.0 Document version: Rev. C © 2016 ROGER sp. z o.o. sp.k. All rights reserved. This document is subject to the Terms of Use in their current version published at www.roger.pl website of the Roger sp. z o.o. sp.k. company (hereinafter referred to as ROGER).

  • Page 2: Description And Specification

     Functional description of HRC series controllers  Installation guide for HRC series controllers In order to acquire the first one it is necessary to obtain Roger consent and sign non-disclosure agreement (NDA). The second one is available at www.roger.pl.

  • Page 3: Power Supply

    Fig. 3 Connection to controller without 12VDC power supply output 3.2 Power supply HRT82TS requires 12VDC nominal power supply. The power must be connected to 12V and GND terminals. Additionally, the GND terminal is used as reference potential for the RACS CLK/DTA bus.

  • Page 4: Front Panel

    (e.g. U/UTP cat. 5) with maximal length of 150m can be used for RACS CLK/DTA communication. 3.4 Front panel HRT82TS is equipped with front icon backlight which is used for signalling proper operation (steady light) or communication problems (blinking). 3.5 Wall mounting and installation guidelines HRT82TS consists of front panel and base which are factory assembled and require manual disassembly prior to installation according to fig.
  • Page 5 HRT82TS Installation Guide Rev.C.doc 2016-10-10 Fig.4 HRT82TS latches and wall mounting...

  • Page 6: Device Programming

    ONFIGURATION 4.1 Device programming The address of factory new HRT82TS is ID=7 and such device is ready to communicate with HRC series controller requiring no additional configuration. The same address is used by HRT82AC air conditioning control panel. Therefore particular controller can operate with only one of mentioned devices at the same time.

  • Page 7: Firmware Update

    [0.5s] elapses. When 0 is selected then failure is not signalled at all. 4.2 Firmware update HRT82TS firmware can be updated with RogerVDM (available at www.roger.pl) after connection to RUD-1 communication interface. Firmware update procedure 1. Connect device to RUD-1 communication interface according to fig. 5 2.

  • Page 8: Memory Reset

    Fig. 8 Firmware update window in RogerVDM software 4.3 Memory reset In order to restore HRT82TS factory default settings place jumper on MEM pins and then restart the device either by placing and removing jumper on RST pins or by switching power supply off and on.

  • Page 9: Product History

    HRT82TS Installation Guide Rev.C.doc 2016-10-10 7. P RODUCT HISTORY Table 6. Product history Version Released Description HRT82TS v.1.0 07/2015 The first commercial version of the product This symbol placed on a product or packaging indicates that the product should not be disposed of with other wastes as this may have a negative impact on the environment and health.
