- Page 1 Hotspot OEM INSTALLATION MANUAL ™...
- Page 2 TABLE OF CONTENTS Introduction Safety Information Resources Required Installation Power Supply Troubleshooting Notes Introduction Hotspot™ was designed and engineered for the mobile lifestyle. The weatherproof, externally-mounted antenna array increases your signal range far beyond a simple “off-the-shelf” mobile hotspot that can lose strength by just moving your device around the campsite.
- Page 3 Installation Locate an area on the unit’s roof to mount the external cellular antenna (Fig. 1B). The area should be relatively flat and be located within 10 feet of the cellular gateway (Fig. 1C) mounting location. Two small coax wires (Fig. 1A) will need to be run between the cellular antenna and the cellular gateway. Fig.
- Page 4 Attach one end of the two coax cables to the coax cable female ends located underneath the external cellular antenna (Fig. 3C). Run the opposite ends of the coax cables through the previously-drilled hole. Make sure the coax cables reach the cellular gateway before affixing the cellular gateway permanently. The cellular gateway (Fig.
-
Page 5: Power Supply
Power Supply Connect the red and black wires (Fig. 6A) from the 12V DC/DC power supply to the unit’s power source. Plug the power supply wire (Fig. 6B) into the back of the cellular gateway (Fig. 5B). 3/4” Secure the 12V DC/DC in-line power supply installing two #8 x stainless steel pan head screws through the provided holes (Fig. -
Page 6: Troubleshooting
Troubleshooting Most concerns with Hotspot can be diagnosed by checking the indicator lights located on the top of the cellular gateway. LED Indicator Light Troubleshooting Chart What Is Letter Description Why? What Should Be Done? Color Happening? OneControl Gateway is No Problems. - Page 7 LED Indicator Light Troubleshooting Chart What Is Letter Description Why? What Should Be Done? Color Happening? Blue Blink on activity. No Problems. Bad or disconnected Replace Ethernet cable Ethernet cable. if necessary. No LAN Device on remote end connection. Check power on mobile of Ethernet cable isn’t device.
- Page 8 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (“LCI”). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty. ...
