Quick Start Guide
IR-Control Unit ZF-310
Control Unit for temperature controller with IR-Interface
Description
The ZF-310 control unit is a compact, easy-to-use tool for temperature controller equipped with the
IR-Interface. It shows the current temperature, and can be used to adjust the set point, if the
controller supports adjustable set points.
Technical Data
Housing:
Power supply:
Display:
Controls:
Ambient temperature:
Safety class:
Degree of protection:
Weight:
plastic
Dimensions: 135 x 70 x 24 mm
2x AA battery (included)
LCD graphic display
push buttons
0°C..40°C
3
IP40
150 g
Seite 1 von 2
Version 1.1 / 2018
Advertisement
Table of Contents
Related Manuals for winkler ZF-310
Summary of Contents for winkler ZF-310
-
Page 1: Technical Data
Control Unit for temperature controller with IR-Interface Description The ZF-310 control unit is a compact, easy-to-use tool for temperature controller equipped with the IR-Interface. It shows the current temperature, and can be used to adjust the set point, if the controller supports adjustable set points. - Page 2 Quick Start Guide IR-Control Unit ZF-310 Operation: link symbol indicates if connected to a set point controller transmission symbol Current temperature inidcates if data is received Change setpoint connect triggers new connection to a controller The IR Control Unit can be switched on by any key. The IR Control Unit automatically tries to establish a connection to a controller.
