Summary of Contents for Rapid Racking Heavy duty work station

  • Page 1 Heavy duty work station Assembly instruction AIW012...
  • Page 2 HEAVY DUTY WORK STATION Tools required: Illustration shows the Rubber mallet 2 shelf Work Station We advise the use of protective gloves and goggles, or eyeglasses when assembling this product. ASSEMBLY 1 Fit plastic feet L, to the bottom of uprights and C, ensuring the keyhole slots are the correct way up as illustrated.
  • Page 3 HEAVY DUTY WORK STATION COMPONENTS Side beam Upper side beam 4 of per workstation 4 of 2 of per T-Bar 305 mm or 380 mm 760 mm or 915 mm Plastic caps Shelf support beam 750 mm 6 of 2 of - Work Station...
