- Page 1 User Manual -- 3G Wide Band Repeater (Model: PORP23W) User Manual 3G Wide Band Repeater (23dBm) REDUTELCO TECHNOLOGY CO.,LTD. 2015 January Information in this manual is subject to change without notice © 2009 Redutelco http:www.redutelco.com | All rights reserved...
-
Page 2: Table Of Contents
User Manual -- 3G Wide Band Repeater (Model: PORP23W) Table of Contents 1 Description .................... 3 2 Product Features ................... 4 3 Technical Specifications ............... 4 4 System Diagram ..................5 5 Applications Example ................5 5.1 Minimum Signal Levels .............. 6 5.2 Custom Applications .............. -
Page 3: Description
User Manual -- 3G Wide Band Repeater (Model: PORP23W) 1 Description Repeater is a device that receives, amplifies and transmits the radiated or conducted RF carrier both in the down-link direction (DL, from the base station to the mobile area) and in the up-link direction (UL, from the mobile to the base station). -
Page 4: Product Features
User Manual -- 3G Wide Band Repeater (Model: PORP23W) frequency carriers are to be repeated or when base station synthesized frequency hopping is used. 2 Product Features High system gain>75dB, High system output power>23dBm Light weight, small dimensions, easy to install ... -
Page 5: System Diagram
User Manual -- 3G Wide Band Repeater (Model: PORP23W) Weight(kg) 0.8kg Shipment Dimension (mm) 250×200×70mm Shipment Weight(kg) 1.5 kg Light @ power supply on Indication LED Light @ repeater work 4 System Diagram The RF link (donor) towards the base station is typically fed from an... -
Page 6: Minimum Signal Levels
User Manual -- 3G Wide Band Repeater (Model: PORP23W) 5.1 Minimum Signal Levels It requires a minimum signal level in the place where install the donor antenna. Failure to provide sufficient input signal will only result in a poor coverage inside the building for this repeater system. -
Page 7: Isolation And Separation
User Manual -- 3G Wide Band Repeater (Model: PORP23W) Most homes or buildings are easily covered by one repeater systems. Some buildings are larger or have multiple areas inside that need coverage. It may need longer cables, more than 2 coverage antennas or other items in order to fully cover your building. -
Page 8: Production Operation
User Manual -- 3G Wide Band Repeater (Model: PORP23W) 6 Production Operation 6.1 Notices Follow below safety items carefully before installation, implementation, maintenance and operation for this product BS and MS port must be connected to donor antenna and service antenna when powers supply on;... -
Page 9: Commissioning
User Manual -- 3G Wide Band Repeater (Model: PORP23W) Step 7: Power up the system and check for signal inside the building. If needed, tune system by moving and or pointing the Donor and Coverage antennas until get the most signal possible. - Page 10 User Manual -- 3G Wide Band Repeater (Model: PORP23W) Hi ATT are used when BTS signal is acquired is too strong via donor antenna (external antenna), which usual are set to lower gain (higher attenuation), and protect repeater to work at good signal situation (NOT Over-power state).This simply setting way is:...
- Page 11 User Manual -- 3G Wide Band Repeater (Model: PORP23W) You can change donor antenna direction or installation position to get bigger signal; You can set attenuation to add or reduce repeater gain; or you can check cable and connector link status to reduce cable loss and insert loss between repeater and antenna.
