iLux Chameleon IS-L8 User Manual

User Guide
To prevent any damage to the video light or harm and personal injury, please read the guide before first use and retain for future
reference.

Introduction

The Chameleon IS-L8 can be used as a light source for both video camcorders and stills photography and can work with
standard hotshoe cameras (for Sony cameras you may also need an extra hotshoe converter).
Light is generated by 8 LED's which have an average lifespan of approximately 10,000hrs

Features

•
Adjustable brightness
•
Powered by lithium ion battery
•
Illumination angle of 65°.
•
Compatible with three third party batteries: NP-F970 / F750 / F550.
•
Universal hotshoe mount
•
Battery power indicator
•
Diffusion filter
•
Colour Temperature reduction filter

Components supplied

1x Chameleon IS-L8
1x Hand grip
1x Battery
1x Travel charger
1x EU pin plug

Product overview

9. Diffusion filter
10. Protective lamp covers
11. Colour temperature reduction filter
To fit the battery simply line up the pins in the battery mount (1) and slide the battery gently downwards until it clicks into place.
To remove, press the battery lock release button (2).
To power the light on, slide the blue on/off switch (3) upwards. To turn off, slide the switch back down.
Brightness is controlled by the dial (4).
Battery charge is shown by the battery power indicator (5).
If required, the angle of head can be adjusted (6) and locked into position (use a coin to secure in place).
To use the light on camera it can be mounted via the hotshoe plate (7).
IS-L8
1. Battery mount pins
2. Battery lock release
3. Power on/off
4. Brightness dial
5. Battery power indicator
6. Angle adjustment lock
7. Hotshoe plate and lock
8. Hand grip

Specifications

Model Chameleon IS-L8
Output power 22W
Illumination 1540 Lux
Illumination range 3 – 10m
Voltage 6V – 17V
Colour temperature 5000 / 6000k
Size 120 x 124 x 32107mm
Weight 740g
12. DC power
input (6˜17V)
