  • Page 2 U.S.A. U.S.FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT INFORMATION TO THE USER NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 3 DECLARATION OF CONFORMITY HYUNDAI IT CORP. Ami-ri Bubal-Eub Ichon-Si Kyungki-Do 467-860 KOREA declare under our sole responsibility that the product: Kind of equipment Type-Designation S40M0G010 / LT46DW001 / S57M0F010 to which this declaration relates is in conformity with the following...
  • Page 4 DIGITAL SIGNAGE Corrections Major features ............1/34 Direction for the use ........... 1/34 Be sure to understand ......... 3/34 Checking product list .......... 5/34 Proper place for product Installation ............6/34 Title and function of each part ......7/34 Front part ..............

  • Page 5: Major Features

    Major features This product has been designed to enable the user ease of use, and display information effectively and conveniently. D320ML/D400ML/D420ML/D460ML : 1366 x 768 WXGA (HD) D525ML/D575ML/D705ML : 1920 x 1080 UWXGA (FHD) Direction for the use This Product is designed to ensure user's safety.

  • Page 6: Remote Control

    DIGITAL SIGNAGE - The product is not suitable for use at visual display workplaces according to §2 of the German Ordinance for Work with Visual Display Units. - The mains plug of the power supply cord shall remain readily operable. - An apparatus with CLASS I construction shall be connected to a Mains socket outlet with a protective earthing connection.

  • Page 7: Be Sure To Understand

    DIGITAL SIGNAGE - Batteries should be inserted using the correct polarity (+,-). - Use only new batteries, do not mix old & new. - Place unit on a stable bracket or surace. - More than 2 persons should work together when moving or installing. - Do not hang on or jump to the product or mounting rack.
  • Page 8 DIGITAL SIGNAGE PREVENTION Temporary afterimage can be alleviated by displaying white or moving frame about 10 hours.(But, permanent afterimage cannot be disappeared according to the property of LCD) This method is used to remove temporary afterimage that may occur after displaying a still frame for a certain times.
  • Page 9 DIGITAL SIGNAGE Check the product Please check the following components provided with the product after you open the box. list Power Cord D-SUB Cable (Option) HDMI cable Product Remote control & batteries able (Option) HDMI to DVI Cable (Option) User's manual please check the following components provided with the product after you open the box and contact the dealer if any missing.
  • Page 10 DIGITAL SIGNAGE Proper location for 1. Locate the product at least 30cm away from the electric appliance or heating product. product installation 2. The product must be placed at least 10cm away from the wall and ground. 3. Keep the product out of direct ray of light and locate screen not to be reflected by the sunlight.

  • Page 11: Title And Function Of Each Part

    DIGITAL SIGNAGE Title and function of Remote control receiving sensor. Menu button : to display menu or exit from the menu. each part Power display LED red-stand by/ Green-working. select button. OSD button. To move down in OSD menu. Front panel Power button ;...
  • Page 12 DIGITAL SIGNAGE Rear panel CVBS OUT AC IN UPGRADE COMPONENT AUDIO IN (L R) AC POWER SWITCH PC AUDIO IN COMPOSITE AUDIO IN (L R) HDMI IN RS-232C OUT HDMI OUT RS-232C IN SPEAKER OUT COMPONENT IN (Y Pb Pr) PC D-SUB IN COMPONENT OUT (Y Pb Pr) PC D-SUB OUT...
  • Page 13 DIGITAL SIGNAGE Remote control To turn the power on or off. Move up in OSD menu. To move left or control the volume down in OSD menu. To move right or control the volume up in OSD menu. To move down in OSD menu. Select in OSD menu.
  • Page 14 DIGITAL SIGNAGE How to Connecting Digital RGB(HDMI) 1. Please ensure that the power to the device is switched off, then connect each cable one after another before restoring power. when connect HDMI to HDMI cable when connect DVI to HDMI cable –...
  • Page 15 DIGITAL SIGNAGE Support timing for HDMI Horizontal frequency Vertical frequency Resolution (KHz) (Hz) 480p 640 x 480p 576p 720 x 576p 720p 1280 x 720p 50 / 60 1080i 1920 x 1080i 50 / 60 640 x 480 31.47 59.94 800 x 600 37.88 60.32...
  • Page 16 DIGITAL SIGNAGE How to Connecting analog RGB (PC D-SUB) 1. Please ensure that the power to the device is switched off, then connect each cable one after another before restoring power. 2. Connect D-SUB to D-Sub cable. Then tighten the screw of the cable after connecting PC D-SUB.
  • Page 17 DIGITAL SIGNAGE Support timing for PC Resolution Horizontal frequency(KHz) Vertical frequency(Hz) 640 x 480 59.94 31.47 800 x 600 60.32 37.88 1024 x 768 48.36 60.00 1360 x 768 47.71 60.00 1280 x 1024 60.00 64.00 1600 x 1200 60.00 75.00 1920 x 1080 60.00...
  • Page 18 DIGITAL SIGNAGE How to Connecting the component 1. Please ensure that the power to the device is switched off, then connect each cable one after another before restoring power. 2. Connect the component cables to Y, Pb, and Pr correctly. Connect BNC cable and tighten.
  • Page 19 DIGITAL SIGNAGE Support timing for Horizontal frequency Vertical frequency component & AV Resolution (KHz) (Hz) 480i 720 x 480i 59.94 / 60 480p 640 x 480p 59.94 / 60 420 x 480p 59.94 / 60 576i 720 x 576i 576p 720 x 576p 720p 1280 x 720p...
  • Page 20 DIGITAL SIGNAGE How to Connecting the the video 1. Please ensure that the power to the device is switched off, then connect each cable one after another before restoring power. 2. Connect video cable and BNC cable, and then tighten. 3.
  • Page 21 DIGITAL SIGNAGE Adjusting OSD and Users can automatically adjust the picture mode according to the input mode. explanation of its function How to Select the Picture Mode 1. Press Menu button. Menu items appear on the screen. 2. Press button to select "Picture" Icon. "PICTURE MODE" is highlighted. 3.
  • Page 22 DIGITAL SIGNAGE How to Set the Desired Users can manually adjust their desired picture Picture 1. Press Menu button. Menu items appear on the screen. 2. Press button to select Picture Icon. "PICTURE MODE" is highlighted. 3. Press buttons to move to Custom and press buttons to select “CUSTOM”.
  • Page 23 DIGITAL SIGNAGE Users can adjust Color as users want. How to Select a Color 1. Press Menu button. Tone Menu items appear on the screen. 2. Press button to select Picture Icon. "Picture Mode" is highlighted. 3. Press buttons to move to "Color Tone" 4.
  • Page 24 DIGITAL SIGNAGE How to Set the Display Users can adjust the display scale as they want Size 1. Press Menu button. Menu items appear on the screen. 2. Press button to select Picture Icon. "Picture Mode" is highlighted. 3. Press buttons to move to "Size".
  • Page 25 DIGITAL SIGNAGE 1. Press Menu button. How to Set Image Menu items appear on the screen. Adjust in PC Mode 2. Press button to select "Picture" Icon. (Supported only in PC "Picture Mode" is highlighted. mode) 3. Press buttons to move to PC and Press buttons to select to "pc"...
  • Page 26 DIGITAL SIGNAGE User can eliminate noises on the screen in AV/Component/HDMI mode.(Not supported in PC mode) How to Set Noise 1. Press Menu button. Reduction(NR) Menu items appear on the screen. 2. Press button to select Picture Icon. "Picture Mode" is highlighted. 3.
  • Page 27 DIGITAL SIGNAGE How to Adjust the Users can adjust sound mode automatically as they want. Desired Audio Mode 1. Press Menu button. Menu items appear on the screen. 2. Press buttons to move to "Sound" icon. 3. Press button to select "Sound" icon. "Mode" is highlighted. 4.
  • Page 28 DIGITAL SIGNAGE How to Select Auto This function will automatically give a similar volume size to each channel. Volume 1. Press Menu button. Menu items appear on the screen. 2. Press buttons to move to "Sound" icon. 3. Press button to select "Sound" icon. "Mode"...
  • Page 29 DIGITAL SIGNAGE 1. Press Menu button. How to Reset Menu items appear on the screen. 2. Press button to select Set up Icon. "Reset" is highlighted. 3. Press buttons to select to "Reset". 4. Press buttons to choose to "Reset". 5.
  • Page 30 DIGITAL SIGNAGE <Go to step 6 if you need to set the "On or Off Timer"> 6. Press buttons to move to "On or Off Timer". 7. Press buttons to select "On or Off Timer" . 8. Press buttons to move between Hour, Minute and on/off and Press buttons to set Hour, Minute and on/off...
  • Page 31 DIGITAL SIGNAGE 1. Press Menu button. How to set osd tone Menu items appear on the screen. 2. Press button to select "setup" icon. "Reset" is highlighted. 3. Press buttons to move to "OSD tone" 4. Press buttons to select to "OSD tone". 5.
  • Page 32 DIGITAL SIGNAGE How to Set the Multi Function 1. Press Menu button.Menu items appear on the screen. 2. Press button to move to "Multi" Icon. 3. Press button to select "Mutli" Icon. "Mutli Function" is highlighted 4. Press buttons to set up and change the location of the screen to be displyed. H Set Count/ V Set Count/Display Sequence / H Edge ADJ / V Edge ADJ / SET ID/ Master (Example of installation) install 3x2 with 6 units Product...
  • Page 33 DIGITAL SIGNAGE Set up Value installation item Product 1 Product 2 Product 3 Product 4 Product 5 Product 6 H Set Count V Set Count Display Sequence H Edge ADJ / V Edge ADJ These are the set up value to make up the un-displayed area of Bezel Part. It can be adjustable according to the contents It is necessary to control via RS232 communication port on PC.
  • Page 34 DIGITAL SIGNAGE How to Set the Heat "Heat control" allows you set up fan operation according to interior temperture of the product Control 1. Press Menu button. Menu items appear on the screen. 2. Press button to move to "Multi" Icon. 3.

  • Page 35: Diagnosis

    DIGITAL SIGNAGE Diagnosis When the product is not working properly, please check before you call customer center. Symptoms How to solve the problem Screen displays late It happens not to show the screen noise when the power is on. after the power is on. Therefore it is not a defect.
  • Page 36 DIGITAL SIGNAGE Symptoms How to solve the problem The screen displays check the volume up and down with remote control and audio without the sound. connection cable No sound from either Confirm the status of the sound balance on OSD menu and check right speaker or left the connection of speaker cable.
  • Page 37 D320ML:170W / D400ML:200W / D420ML:220W / D460ML:260W Dimemsion(WxDxH/mm) D320ML : 766 X 456 X 122 / D400ML : 920 X 532 X 123 D420ML : 990 X 585 X 123 / D460ML : 1056 X 608 X 123 Interior dimension of box...
  • Page 38 DIGITAL SIGNAGE D525ML/D575ML Model D525ML/D575ML/D705ML D705ML 1920 x 1080 Pixel( Full HD) D525ML : 1152.00 x 684.00 / Pixel pitch 0.60 Screen size (HxV/mm) D575ML : 1251.36 x 703.89 / Pixel pitch 0.65 D705ML : 1549.44 x 871.56 / Pixel pitch 0.81 Recommended resolution 1920 x 1080 @ 60Hz Digital RGB, Analog RGB, Component, Video, PC Audio L/R,...
