Amphenol Procom CSR-DMT User Manual

Bi-directional digitally controlled amplifier that offers an increase of signal strength in small and medium-sized rooms.
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
CSR-DMT
channel selective digital TETRA repeater

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSR-DMT and is the answer not in the manual?

Questions and answers

Summary of Contents for Amphenol Procom CSR-DMT

  • Page 1 User Manual CSR-DMT channel selective digital TETRA repeater...
  • Page 2 CSR-DMT channel selective digital TETRA repeater Rev 3-NM, Issued Nov. 2017 Page 2 of 16...

  • Page 3: Table Of Contents

    4.2 Overview .......................... 12 4.3 Establishing a connection ....................12 4.4 Configuration interface ..................... 13 4.7 Firmware upgrade......................14 5.0 APPENDIX ........................... 15 5.1 Technical specifications ....................15 5.2 CSR-DMT view ........................ 16 COPYRIGHT ..........................16 Page 3 of 16...

  • Page 4: Contact Information

    CONTACT INFORMATION Procom A/S Address: Smedetoften 12 3600 Frederikssund Denmark Phone: +45 48 27 84 84 Web: www.amphenolprocom.com 1.0 GENERAL INFORMATION 1.1 Abbreviations Analog to Digital Converter Automatic Gain Control Base Transceiver Station Digital to Analog Converter Downlink Electrostatic Discharge ETSI European Telecommunication Standards Institute GPRS...

  • Page 5: Warnings

    CSR-DMT is based on a digital filtering approach thanks to that the CSR-DMT is very flexible in continuously changing conditions of mobile communication systems. The digital filter can be reconfigured in a custom desired way: •...

  • Page 6: Hardware Description

    2.1 Block diagram Figure 1. CSR-DMT block diagram Presence of various nodes can be different for different ordering options of CSR-DMT. 2.2 Filters characteristics In this section digital filter characteristics are described. Digital filter node is purely software based, thanks to that it is possible to reconfigure selective filters in a desired way without any change to the hardware.
  • Page 7 If needed the repeater pass band can be constructed from two or more segments. For instance using such a composite method with filters from group 1 (see table above) it is possible to make wideband filter with best selectivity properties. Applying composite method it must be taken into account the real transition band in amplitude-frequency response of the filter.
  • Page 8 Figure 3. One 25 kHz segment Figure 4. One 100 kHz segment Figure 5. One 5 MHz segment Page 8 of 16...

  • Page 9: Hardware Agc

    For installation convenience control part (LEDs, USB, RESET button) is placed on inside of the CSR-DMT in front position. On bottom side of the CSR-DMT RF connectors, power supply input and other additional connections are placed.
  • Page 10 Figure 6. CSR-DMT bottom view and top view Page 10 of 16...

  • Page 11: Installation

    Red LED, error event indicator USB input Reset button Repeater unit Power supply module Indoor antenna connector Pressure valve Power supply 230VAC-input (PG-type) Donor/Outdoor antenna connector 3.0 INSTALLATION 3.1 Mechanical installation Figure 7. CSR-DMT mechanical dimensions Page 11 of 16...

  • Page 12: Electrical Installation

    (both 32 bit or 64 bit systems are supported). 4.2 Overview CSR-DMT control software is a GUI tool for repeater configuration. It can be used to set repeater frequency response, adjust gain and monitor health state. Configuration interface (see section “4.4 Configuration interface” of this manual) is used to: •...

  • Page 13: Configuration Interface

    Channel attenuation can be adjusted manually for each channel (figure 8, 6 uplink) and also for all four channels of up (figure 8, 7 uplink) and down links jointly with physical attenuators (see figure 1 “CSR-DMT block diagram” for details). Resulting gain for each channel is displayed in the “Total Gain” boxes for up and down links.

  • Page 14: Firmware Upgrade

    “Frequencies” tab controls. Loaded configuration can be sent to repeater using “Send Config” button. 4.7 Firmware upgrade CSR-DMT firmware is user upgradeable. Firmware upgrade can be performed locally over a direct USB connection. To perform the upgrade, please contact manufacturer. Manufacturer will supply all the necessary software and up to date instructions.

  • Page 15: Appendix

    5.1 Technical specifications Table 3. Technical specifications Parameter Specification Frequency range* CSR-DMT-380: Uplink: 380-385 MHz & Downlink: 390-395 MHz CSR-DMT-410: Uplink: 410-415 MHz & Downlink: 420-425 MHz Uplink: 1 up to 4 Number of independent band-segments Downlink: 1 up to 4...

  • Page 16: Csr-Dmt View

    5.2 CSR-DMT view Figure 10. CSR-DMT enclosure (IP55), closed top panel Figure 11. CSR-DMT enclosure, open top panel COPYRIGHT © Copyright 2011-2017 Procom A/S. All rights reserved. All information contained in given manual has been revised thoroughly. However, Procom A/S accepts no liability for any omissions or faults and assumes no responsibility for its use.
