Contractors Wardrobe 6000H-180 Installation Instructions Manual

Shower doors

Advertisement

Quick Links

Model 6000H-180
Illustrated Installation
Instructions
Shower Doors
DESIGNERS • MANUFACTURERS
26121 Avenue Hall • Valencia, CA 91355
(661) 257-1177 • Fax (661) 257-4907
Or visit our website at: www.cwdoor.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6000H-180 and is the answer not in the manual?

Questions and answers

Summary of Contents for Contractors Wardrobe 6000H-180

  • Page 1 Model 6000H-180 Illustrated Installation Instructions Shower Doors DESIGNERS • MANUFACTURERS 26121 Avenue Hall • Valencia, CA 91355 (661) 257-1177 • Fax (661) 257-4907 Or visit our website at: www.cwdoor.com...
  • Page 2 Illustrated Parts Breakdown IPB Drawing Model 6000H-180 12 23 23 16 17 Qty. Part # Part Description No. Qty. Part # Part Description G1040 Gray 3/16″ - 1/4″ Vertical Press-In Vinyl A7017 Header - #6000 G1050 Gold 3/16″ - 1/4″ Vertical Press-In Vinyl...
  • Page 3 If it is out of level more than that, If you find that any parts are damaged or missing, you may need to order custom wall jambs. refer to the parts list and IPB Drawing and contact Contractors Wardrobe ’s Customer Service Department ® Tools you will need: at 661-257-1177.
  • Page 4 3. If this unit is being installed in a fiberglass pan, cut the STEP 4 Installing the In-Line Glass Panel Bottom Curb/Sill (#2) and Wall Jambs (#6) at a slight angle 1. Place the two Setting Blocks (#16) into the Bottom (about 45°) where they meet to accommodate the rounded Curb/Sill (#2) (See Figure 5).
  • Page 5 STEP 8 Installing and Adjusting the Door and Insert Jamb Installing the door panel may be easier if you have someone to assist you. 1. Temporarily install the Framed Door with CW Rotary ® Gear Hinge Assembly with Magnetic Seal (#4) into the Slip Jamb Male (#5).
  • Page 6 STEP 11 Installing the Drip Rail STEP 9 Glazing the Vinyl into the In-Line Panel 1. With a pair of scissors cut the clear Drip Rail Gasket (#12) 2″ longer than the Drip Rail (#11). Cut a notch into 1. Remove the 2″ strips of temporary Vertical Press-In the strike side of the Drip Rail Gasket (#12) (see Figure Vinyl (#18) and shift In-Line Glass Panel (#25) to obtain 15).
  • Page 7 ® This is only one of a large line of shower enclosures and high quality wardrobe door products. If you like this product, please contact Contractors Wardrobe ® for more information about our many beautiful wardrobe doors in bi-pass and bi-fold styles with steel, aluminum and hardwood frames.
