oticon ConnectLine Digital Office Phone Kit Easy Setup Instructions

Oticon ConnectLine
Digital Office Phone Kit
Easy Setup Instructions
1. HARD-WIRED SETUP METHOD
You will use Streamer Pro in conjunction with
the Sennheiser box, coiled phone cable, and AUX
cable, pictured below:
Sennheiser box & coiled phone cable
AUX cable
Handling calls using the hard-wired setup method:
• No alerts will be heard through the hearing instruments. (the ring
sounds on the phone only)
• Make sure the AUX input is selected on Streamer Pro. Press the AUX
button if necessary. (note: not the phone button)
•
Ensure the phone button on the Sennheiser box is in the up position.
(not pressed down)
• When a call comes through, pick up the phone receiver and place it on
the desk or table surface. Conduct the conversation through the
Streamer Pro as usual. Replace the receiver when through.
• For outgoing calls, lift the receiver and place it on the desk or table
surface. Dial the number and the call will go through. Replace the
receiver when the call is ended.
If your digital office phone has a headset port, you can also set up the digital office phone kit using this
functionality. Instructions for this method are available in the Product Literature section at
www.oticonusa.com/connectline in the booklet called "Digital Office Phone Kit Setup Guide."
These instructions guide you through setting up ConnectLine's digital
office phone solution. There are two methods for installation:

Setup Instructions

(Before beginning, insert the included battery into the Sennheiser device.)
Step 1
Insert coiled cable into the back port of the
Sennheiser box as pictured.
Step 3
Insert phone receiver cord into front of
Sennheiser box.
1. Hard-wired setup
2. Wireless setup
Step 2
Remove phone receiver cord from
phone base & replace with coiled cable from
Sennheiser box. The coiled phone cable will
now connect the Sennheiser box and phone
base.
Step 4
Insert the AUX cable into the headset jack on
the Sennheiser device as pictured. Plug the
mini jack end into Streamer Pro. *
Control settings on the bottom
of the Sennheiser box:
•
Set the ABC switch to the
position that provides the
best sound quality.
•
Rotate the small volume
control dial to achieve the
best balance of sound quality
and volume for both parties.
*Ensure Streamer Pro is around the user's neck
