- Page 1 ValkDouble Installation manual Van der Valk Solar Systems Solar Mounting Systems Version 07 | EN...
-
Page 2: Table Of Contents
Page 06 Mounting subassembly Page 07 Push-rods Page 08 Ballast Page 09 End clamp Page 10 Panel clamp Page 11 DC cable clamp Page 12 Table of contents ValkDouble Van der Valk Solar Systems Solar Mounting Systems Version 07 | EN... - Page 3 Congratulations on buying the ValkDouble® mounting system and on helping the environment by deciding to install solar panels. The ValkDouble® mounting system is an universal mounting system that can be used to install 2 standard solar panels in a landscape set-up one above the other, with a tilt angle of 10°, on a flat roof with a height up to 10 m.
- Page 4 Before installing the ValkDouble® mounting system, make sure that you carefully sweep the roof area. The ballast calculation for the ValkDouble® mounting system (see page 5 of the manual) only applies for flat roofs and roofs with a slight pitch of up to 5°.
-
Page 5: Ballast Requirements Page
Ballast requirements General ® The ValkDouble mounting system must be weighted down by tiles, which will be placed at position G2. Start by choosing the wind area in which the system will be installed from the overview on page 6. -
Page 6: Selection Table Page
Selection table: Minimum number of kilograms per position G2. Based on: * Category: Town (sites more than 1km inside town boundary - area where at least 15% of the surface is covered with buildings with an average height above 15m) * Distance to shoreline: >10km * Maximum height above sea level: <100m... - Page 7 Necessary tools for ValkDouble Wrench 13 Socket 13 Cordless drill Torx bit T-30 (for socket 13 and bit T-30)
-
Page 8: Measurements (Mm) Valkdouble
Measurements (mm) ValkDouble 1300 2000 Panel length Advised pitch measure 3300 (Based on sun angle of 14,5 ) 2178... -
Page 9: Front Mass Block
Front mass block 74.18.01600 15Nm Detail A 75.05.20 72.96.10 77.40.65 M8x65 77.40.08 3rd hole of roof carrier... -
Page 10: Rear Mass Block
Rear mass block 15Nm 75.05.20 Detail A 72.96.10 M8x220 74.79.74 77.40.06 77.40.08 2nd hole from end of roof carrier... -
Page 11: A-Frame Connector
A-frame connector 72.44.20 Detail A 15Nm Mount hole to the front The groove of the bolt correponds with the orientation of the bolt head. 3rd hole from end of roof carrier 2nd hole of roof carrier... -
Page 12: Push-Rods
Push-rods G13.03.22.0825.00.00 Detail A 15Nm 77.42.20 M8x20 77.40.06 4th hole from end of roof carrier The groove of the bolt correponds with the orientation of the bolt head. 4th hole of roof carrier... -
Page 13: Subassembly Profile
Subassembly profile 72.7.2100 15Nm Detail B 72.44.50 15Nm 72.44.14 Detail A M8x20 77.40.20 77.40.06... -
Page 14: Mounting Subassembly
Mounting subassembly profile Detail A Subassembly profile 77.40.71 M8x70 15Nm 77.40.06... -
Page 15: Push-Rods
Push-rods G13.05.77.0350.00.00 Detail A G13.03.22.0850.65.65 Detail B 77.40.71 M8x70 15Nm 15Nm 77.40.06... -
Page 16: Ballast
Ballast 15Nm 72.51.40 Detail A 77.40.06 Not included Tile Tile 300x300x45 mm Refer to the ballast table in front of this manual. 2 extra tiles 4 extra tiles 6 extra tiles 8 extra tiles Turn tile clamp upside down. -
Page 17: End Clamp
End clamp 72.15.52 Detail A Detail A Take the End Clamp out of it's slot to make the assembly easier. The End Clamp can only be turned clockwise, so make sure that the End Clamp is placed the right way. Detail A Put the End Clamp in the right slot to continue the assembly. -
Page 18: Panel Clamp
Panel clamp 72.15.50 Detail A (To mount end clamp see page 10) -
Page 19: Dc Cable Clamp
DC cable clamp 73.20.01 Max. cable diameter 9 mm Mount cable clamp on the panel. - Page 20 It concentrates solely on developing and manufacturing solar panel mounting systems Developer and producer of solar mounting for pitched roofs, flat roofs and open fields. Van der Valk Solar Systems also has an office and warehouse located in the UK.
