SilverStone ECP01 Manual

04
Product installation is complete.
4. Damit ist die Produktinstallation abgeschlossen.
4. La instalación del producto está completa.
4. Установка устройства завершена .
4.本产品安装完成。
4. 제품 설치가 완료되었습니다.
电源转接板 有毒有害物质/元素及其化学含量表
铅 汞 镉
部件名称
(Pb) (Hg) (Cd)
卡条（金属）
○ ○ ○
电子卡
○ ○ ○
线材
○ ○ ○
螺丝
○ ○ ○
包材
○ ○ ○
○：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T11364-2014标准规定的限量要求以下。
×：表示该有毒有害物质在该部件材料中的含量超出
SJ/T11364-2014标准规定的限量要求。
本表中有×的部件均符合欧盟RoHS法规，即欧盟第
2011/65/EU号指令要求。
Warranty Information
This product has a limited 1 year warranty in North America, Europe, and Australia.
For information on warranty periods in other regions, please contact your reseller or SilverStone authorized distributor.
Warranty terms & conditions
1. Product component defects or damages resulted from defective production is covered under warranty.
Defects or damages with the following conditions will be fixed or replaced under SilverStone Technology's jurisdiction.
a) Usage in accordance with instructions provided in this manual, with no misuse, overuse, or other inappropriate actions.
b) Damage not caused by natural disaster (thunder, fire, earthquake, flood, salt, wind, insect, animals, etc...)
c) Product is not disassembled, modified, or fixed. Components not disassembled or replaced.
d) Warranty mark/stickers are not removed or broken.
Loss or damages resulted from conditions other than ones listed above are not covered under warranty.
2. Under warranty, SilverStone Technology's maximum liability is limited to the current market value for the product (depreciated value, excluding
shipping, handling, and other fees). SilverStone Technology is not responsible for other damages or loss associated with the use of product.
3. Under warranty, SilverStone Technology is obligated to repair or replace its defective products. Under no circumstances will SilverStone
Technology be liable for damages in connection with the sale, purchase, or use including but not limited to loss of data, loss of business, loss of
profits, loss of use of the product or incidental or consequential damage whether or not foreseeable and whether or not based on breach of warranty,
contract or negligence, even if SilverStone Technology has been advised of the possibility of such damages.
4. Warranty covers only the original purchaser through authorized SilverStone distributors and resellers and is not transferable to a second hand
purchaser.
5. You must provide sales receipt or invoice with clear indication of purchase date to determine warranty eligibility.
6. If a problem develops during the warranty period, please contact your retailer/reseller/SilverStone authorized distributors or SilverStone
http://www.silverstonetek.com.
Please note that: (i) You must provide proof of original purchase of the product by a dated itemized receipt; (ii) You shall bear the cost of shipping
(or otherwise transporting) the product to SilverStone authorized distributors. SilverStone authorized distributors will bear the cost of shipping
(or otherwise transporting) the product back to you after completing the warranty service; (iii) Before you send the product, you must be issued a
Return Merchandise Authorization ("RMA") number from SilverStone. Updated warranty information will be posted on SilverStone's official website.
Please visit http://www.silverstonetek.com for the latest updates.
Additional info & contacts
For North America (usasupport@silverstonetek.com)
SilverStone Technology in North America may repair or replace defective product with refurbished product that is not new but has been functionally tested.
Replacement product will be warranted for remainder of the warranty period or thirty days, whichever is longer. All power supplies should be sent
back to the place of purchase if it is within 30 days of purchase, after 30 days, customers need to initiate RMA procedure with SilverStone Technology
in USA by first downloading the "USA RMA form for end-users" form from the below link and follow its instructions.
http://silverstonetek.com/contactus.php
For Australia only (support@silverstonetek.com)
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
Please refer to above "Warranty terms & conditions" for further warranty details.
SilverStone Technology Co., Ltd. 12F No. 168 Jiankang Rd., Zhonghe Dist., New Taipei City 235 Taiwan R.O.C. + 886-2-8228-1238
(standard international call charges apply)
For Europe (support.eu@silverstonetek.de)
For all other regions (support@silverstonetek.com)
4. L'installation du produit est terminée.
4. L'installazione del prodotto è completa.
4.本產品安裝完成。
4.これで製品のインストール完了です。
六价铬 多溴联苯 多溴二苯醚
(Cr(VI)) (PBB) (PBDE)
○ ○ ○
○ ○ ○
○ ○ ○
○ ○ ○
○ ○ ○
产品合格证
检验员：检01
生产日期：见产品条码
Dual output power adapter card
with 12V DC jack and 5V USB Type-A port
ECP01 ECP01
Dual output 12V DC jack up to 5A and 5V USB Type-A port up to 3A
USB port compliant with USB battery charging specification 1.2
Intelligent over current protect system
Includes DC to DC cable with 1.2m length, DC dim 2.5mm to DC dim
2.1mm Power Plug Adaptor
Includes optional low profile bracket for supporting low profile cases
Introduction
SilverStone's ECP01 is a dual output power adapter card that can transfer a computer's internal
power to external 12V DC jack and 5V USB Type-A port via peripheral 4-Pin or SATA 15-Pin
connectors. This adds flexibility to your PC in being able to support additional power to devices such
as external drives or USB chargers. ECP01's DC jack connector can provide 12V up to 5A and its
USB Type-A port can support 5V up to 3A. It is also complaint with USB battery charging specification
1.2 so it can charge mobile devices quickly while the built-in over current protection mechanism
helps to ensure connected devices are well protected when charging.

Specifications

Model No.
Input connector and current
Output connector and current
Intelligent protect system
Cable length and specifications
Net Weight
Dimension
NO: G11228300
V USB Type-A port
SST-ECP01
Peripheral 4-Pin female connector x 1 (12V/5V) or SATA 15-Pin female connector x 1 (12V/5V)
DC jack connector x 1 (12V/5A) USB Type-A female connector x 1 (5V/3A)
Over current protection
DC plug 1.2m cable with 18 AWG x 1 and OD 3.5mm DC dim 2.5mm to DC dim 2.1mm adapter
35g
120mm (W) x 21mm (H) x 53mm (D)
