Southern Car Parts C6 Tail Light Seal Installation Instructions

Hide thumbs
1
2
3

Advertisement

Table of Contents

Southern Car Parts
C6 Tail Light Seal Installation Instructions.

Tools Needed

Rag, T-15 Torx Head, Lubricant (soapy water compound, very small amount of car wash or
dish soap mixed with water, ½ tsp per ever gallon of water).
Remove the tail lights one at a time with a T-15 Torx head...One screw at the top of the lens.
Clean the edges of the tail light with a wet rag...Heck while you're at it clean all of the grime
from behind the tail light as the seal will prevent that from happening again.
All clean and ready for the new seal...
Peel the adhesive backing (yellow strip) off the seal. Starting at the top of the taillight, gently
press the seal onto the tail light all the way around the perimeter. You want the big (thick) side
of the seal facing OUT and the thin side facing the front of your car (into the bumper). You
want the seal to be just about flush with the outer edge of the light lens.
www.southerncarparts.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C6 Tail Light Seal and is the answer not in the manual?

Questions and answers

Summary of Contents for Southern Car Parts C6 Tail Light Seal

  • Page 1 Southern Car Parts C6 Tail Light Seal Installation Instructions. Tools Needed Rag, T-15 Torx Head, Lubricant (soapy water compound, very small amount of car wash or dish soap mixed with water, ½ tsp per ever gallon of water). Remove the tail lights one at a time with a T-15 Torx head...One screw at the top of the lens.
  • Page 2 Southern Car Parts C6 Tail Light Seal Installation Instructions. Seal is installed and ready to reinsert into housing. For the next step you are going to need a tiny amount of lubricant (this is very important, without the lubricant, installation of the taillight will be very difficult without shifting the position of your seal) Before starting, double check the clip in the fascia where the screw threads into and make sure it is tight and not bent out in any way.
  • Page 3 Southern Car Parts C6 Tail Light Seal Installation Instructions. Reinstall the screw and repeat for each light. Total time is about 5 mins per light max… Finished Product www.southerncarparts.com...
