Propel Trampolines URBAN RENEGADE Instruction Manual

UNDERSTANDING TRIM ADJUSTMENTS
Turn Left/Right Trim
• If your car cannot run straightly, you may need to utilize the LEFT AND RIGHT TRIM buttons.
• From time to time you may have to adjust the LEFT AND RIGHT TRIM to left and right to ensure the
car will fun straight and respond accurately to control commands.
Forward/Backward Trim
• If your car is moving forwards or backwards automatically, you may need to adjust the
FORWARD/BACKWARD TRIM buttons.
• From time to time you may have to adjust the FORWARD/BACKWARD TRIM to ensure the
car will stay and respond accurately to your commands.
WARNING
DO NOT USE YOUR URBAN RENEGADE IN FOUL WEATHER!
TROUBLESHOOTING
Before sending your car in for repair, please check for a solution below.
Problem Possible Cause(s)
Car will not move Weak batteries; no batteries Install new batteries in remote
control and charging car battery
Car does not respond properly Car and remote not sync properly Refer to sync section to re sync
to remote control your car and remote
Another RC car may be transmitting Move to a new location where no
on the same radio frequency other RC cars are present
Car loses connection to Using car in a small enclosed area Move outdoors to a large open area
remote control
Using car indoors
Low batteries in Transmitter or Install new batteries in remote
Vehicle
control or charging your car
Car battery has fully charged, Driving car for too long at high Let car sit still for 10-15 minutes
but slower than normal speeds, causing motor to overheat
SAFETY WARNINGS!
• Improper use of batteries may lead to overheating, breakage or leaking.
- Do not mix old and new batteries.
- Do not mix different battery brands.
- Install batteries with correct polarity. The flat side (negative terminal) of the battery should rest
against the spring.
Remove dead batteries immediately.
-
Avoid liquids, which can short circuit the batteries.
-
The car or remote will become unresponsive when batteries are low, at which point you should replace
-
all batteries with new ones.
Remove the batteries if you will not use the car for a long time.
-
Avoid using near furniture or glass to prevent damage to these objects.
•
Do not use car on roads where real cars are in use. Serious physical harm or death may result.
•
Do not use car in areas crowded with people as this may result in harm to car and/or people. Choose
•
a safe location free of people and real cars.
Do not use car during a storm or when lightning or thunder are present.
•
• Do not use in a wet , sandy or muddy environment as car may become damaged.
• Do not bend the antenna. It may break, exposing sharp metal that can cause injury.
• Do not pull on any wires that are part of the car. Such action may cause the wires to break and the car
to malfunction.
• Keep fingers, hair and clothes away from the car's spinning tires. Failure to do so may result in
physical injury.
• Never aim the car at other people.
• Do not throw the car or purposely hit it with any object.
• Store car in a cool environment, away from high-temperature sources such as fires, stoves, radiators, etc.
• This car has no user-serviceable parts. Do not attempt to modify components or circuit board.
FCC Part 15 B Notice
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Solution
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions :
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
Conforms to safety requirements of ASTM, CPSIA and FCC.
PROPEL RC
15760 W Hardy Rd Suite 400 Houston Texas 77060 tel: 949.566.9573
© 2013 Rooftop Brands™. All Rights Reserved. www.propelrc.com .
Urban Renegade
and are trademarks of Rooftop Brands.
™ TM
Made in China
URBAN RENEGADE
High Speed Racer
INSTRUCTION MANUAL
Thank you for choosing Propel RC Urban Renegade . With proper care, your new
TM TM
Urban Renegade will provide you with many hours of enjoyment. Please read this
instruction manual completely before using the product for the first time, and then
keep this manual in a handy place for future reference.
14
Colors and styles may slightly vary.
