Hoover CH90040 Manual

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS!
When using an electrical appliance, basic precautions should always be followed, including the following:
1. SAVE THESE INSTRUCTIONS – This manual contains important safety and operating instructions for battery charger
Model CH90002.
2. Before using battery charger, read all instructions and cautionary marking on battery charger, battery, and product using battery.
3. CAUTION – To reduce risk of injury, charge only lithium-ion type rechargeable batteries. Other types of batteries may burst causing personal
injury and damage.
WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:
• This product is intended for Commercial use only.
• Do not use the unit, store, or charge battery outdoors or on wet surfaces. Do not allow to get wet.
• Do not allow to be used as a toy. Not intended for use by children age 12 and under. Close supervision is necessary when used near children. To
avoid injury or damage, keep children away from product, and do not allow children to place fingers or other objects into any openings.
• Use only as described in this manual. Use only manufacturer's recommended attachments and products.
• Do not use charger with damaged cord or plug. If appliance or charger is not working as it should, has been dropped, damaged, left outdoors, or
dropped into water, take it to a service center prior to continuing use.
• Do not pull or carry charger by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners. Do not place product
on cord. Do not run appliance over cord. Keep cord away from heated surfaces.
• Do not place product on cord. Do not run appliance over cord. Keep cord away from heated surfaces.
• Do not unplug charger by pulling on cord. To unplug charger, grasp the plug, not the cord.
• Do not handle charger – including charger plug and charger terminals, or appliance – with wet hands.
• Do not incinerate the charger, battery, or appliance even if it is severely damaged. The batteries can explode in a fire.
• This product includes rechargeable lithium-ion batteries. Do not expose batteries to high temperatures, as they may catch fire and/or explode.
• Do not expose battery to crushing, incineration or similar actions.
• Do not dispose of battery in a fire or trash compactor. See battery disposal section for directions.
• Do not attempt to disassemble battery.
• Unplug the charger from the outlet before any routine cleaning or maintenance.
• Leaks from battery cells can occur under extreme conditions. If any liquid gets on the skin wash quickly with soap and water. If any liquid gets into
the eyes, do not rub eyes, immediately flush them with clean water continuously for a minimum of 15 minutes. Seek medical attention immediately.
• Use only the charger (Hoover Part #CH90002) supplied by Hoover
• Use only the battery (Hoover Part #CH90040) supplied by Hoover
• Do not touch or insert objects into battery pack or charger terminals.
• The charger is for indoor use only. Be sure to always keep the battery and charger in a dry place.
• Do not attempt to short circuit the battery or charger terminals.
• This product includes rechargeable lithium-ion batteries. Do not expose batteries to high temperatures as they may catch fire and/or explode.
• Keep charger away from areas where oil may be present.
CAUTION: TO REDUCE THE RISK OF DAMAGE:
• Store appropriately indoors in a dry place. Do not expose charger or batteries to freezing temperatures.
WARNING: THIS PRODUCT CONTAINS CHEMICALS, KNOWN TO THE STATE OF
CALIFORNIA TO CAUSE CANCER AND BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM.
WASH HANDS AFTER USING.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, THE CHARGER HAS A POLARIZED
PLUG (ONE BLADE IS WIDER THAN THE OTHER). THIS PLUG WILL FIT IN A POLARIZED
OUTLET ONLY ONE WAY. IF THE PLUG DOES NOT FIT FULLY IN THE OUTLET, REVERSE THE
PLUG. IF IT STILL DOES NOT FIT, CONTACT A QUALIFIED ELECTRICIAN TO INSTALL THE
PROPER OUTLET. DO NOT CHANGE THE PLUG IN ANY WAY.
1
2
4
3
CHARGING THE M-PWR
NOTE: Batteries are shipped in a low charge condition to prevent possible problems. You should charge them before first use.
Only one battery is charged at a time. When two batteries are in place, the battery with the most power remaining will be charged first. This
ensure s the fastest time to full charge.
To charge the battery, Charger LED Status
slide battery into charger. Indicator will turn green
Push backward until when battery is fully
battery clicks into place charged.
and LED Status Indicator
If the charger flashes red,
is lit.
an error has occurred.
Remove and replace
battery.

TROUBLESHOOTING

What does it mean when charger light is... Charging a Hot Battery Pack:
When using a vacuum continuously,
FLASHING
Battery Charging
the battery may become hot. A hot
GREEN
battery may be placed directly on the
charger but charging will not begin
SOLID GREEN Fully Charged
until the battery temperature cools
YELLOW Leave Battery on Charger.
to within an acceptable temperature
It's too hot
range. When a hot battery is placed on
or cold to charge.
the charger, the Yellow LED will remain
lit until the battery is cool enough to
FLASHING RED Call us at
begin charging.
1-800-944-9200

BATTERY DISPOSAL

BATTERY DISPOSAL WARNING: RISK OF EXPLOSION OR EXPOSURE TO TOXIC MATERIAL.
CAUTION:
The battery used in this device may present a risk of fire or chemical burn if mistreated. Do not disassemble, heat above
manufacturer's maximum temperature limit (60°C/140°F), or incinerate. Replace battery with Hoover
of another battery may present a risk of fire or explosion. Dispose of used battery promptly. Keep away from children. Do not disassemble and do not
dispose of in fire. Do not attempt to disassemble the battery or remove any component projecting from the battery terminals. The battery and charger
have no user serviceable parts. Fire or injury may result. Prior to disposal, protect exposed terminals with heavy insulating tape to prevent shorting.
LITHIUM-ION BATTERIES:
The battery must be collected, recycled or disposed of in an environmentally sound manner. The EPA certified
RBRC Battery Recycling Seal on the lithium-ion (Li-ion) battery indicated Techtronic Industries, a corporate affiliate of Hoover
participating in an industry program to collect and recycle these batteries at the end of their useful life, when taken out of service in the United
States or Canada. The RBRC program provides a convenient alternative to placing used Li-ion batteries into the trash or the municipal waste
stream, which may be illegal in your area. Please visit www.rbrc.org/call2recycle/ for information on Li-ion battery recycling and disposal
bans/restrictions in your area. Hoover ® Commercial involvement in this program is part of our commitment to preserving our environment and
conserving our natural resources.
SERVICE & WARRANTY

SERVICE INFORMATION

ANY SERVICING SHOULD BE DONE BY AN AUTHORIZED SERVICE REPRESENTATIVE.
Call 1-800-944-9200 USA & Canada.
In the event that further assistance is required, visit an authorized service center. Find one nearest you by visiting our website at
www.HooverCommercial.com. Costs of any transportation to and from any place of repair are to be paid by the owner. Always identify your
product by the model number and manufacturing code when requesting information or ordering replacement parts. (The model number and
manufacturing code for the vacuum appears on the bottom of charger and side of battery.)
CONTACT US COMMUNIQUEZ AVEC NOUS COMUNÍQUESE CON NOSOTROS: 1-800-944-9200
• •
Battery models · Modèles de piles · Modelos de las baterías
CH90040
Charger models · Modèles de chargeurs · Modelos de los cargadores
CH90002
Commercial to recharge.
®
® Commercial. Other batteries may burst causing serious personal injury or damage.
FEATURES
Battery
1. LED Charge Level Indicator
2. Charge Level Check Button
3. Release Button
5
4. Connection Terminals
Charger
5. LED Indicator
40V BATTERY
™
66%–100% Charged
33%–66% Charged
10%–33% Charged
0%–10% Charged
When charging, the fully To remove battery, press
lit LEDs on the battery the release button and
will indicate charge level. slide battery forward
while holding down on
charger base.
CHARGING AMBIENT TEMPERATURE RANGE:
5 °C – 50 °C (41 °F – 122 °F)
Charging a Cold Battery Pack:
A cold battery may be placed directly
on the charger but charging will not
begin until the battery temperature
warms to within an acceptable
temperature range. When a cold
battery is placed on the charger, the
Yellow LED will remain lit until the
battery is warm enough to begin
charging.
Commercial Battery Part #CH90040 only. Use
®
® Commercial, is voluntarily
HOOVERCOMMERCIAL.COM
•

1 YEAR LIMITED WARRANTY

WHAT THIS WARRANTY COVERS
When used and maintained in normal household use and in accordance with the Owner's Guide your Hoover
are warranted against original defects in material and workmanship for the period indicated in the above table (a.) date of purchase (the
"Warranty Period"). During the Warranty Period, Hoover Commercial will provide labor and parts, at no cost to you, to correct any such defect
®
in your Hoover ® Commercial M-PWR ™ 40V products and (b.) will provide a replacement battery at no cost to you, to correct defects in the
battery that came with your Hoover Commercial M-PWR
® ™
HOW TO MAKE A WARRANTY CLAIM
If this product is not as warranted, take or send the product to a Hoover
purchase. If the batteries are not as warranted, either take or send the batteries along with proof of purchase to an Hoover
dealer or contact Hoover Commercial at 1-844-800-5093. For an automated referral to authorized service outlets in the U.S.A., phone: 1-800-944-
®
9200 or visit Hoover ® Commercial online at www.HooverCommercial.com.
WHAT THIS WARRANTY DOES NOT COVER
This warranty does not cover belts, filters and brush rolls, improper maintenance of the product, damage due to misuse, acts
of God, nature, vandalism or other acts beyond the control of Hoover
country in which the product was initially purchased and resales of the product by the original owner. This warranty does not
cover pick up, delivery, transportation or house calls. However, if you mail your product to an Hoover
Service Center for warranty service, cost of shipping will be paid one way. Please call the Hoover
on how to ship this product. This warranty does not apply to products purchased outside the United States, including its territories and
possessions, a U.S. Military Exchange and Canada.
OTHER IMPORTANT TERMS
This warranty is not transferable and may not be assigned. This Warranty shall be governed and construed under the laws of the state of
Ohio. The Warranty Period will not be extended by any replacement of batteries or parts or repair performed under this Warranty. THIS
WARRANTY IS THE EXCLUSIVE WARRANTY AND REMEDY. ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSE, ARE DISCLAIMED. IN NO EVENT WILL HOOVER
LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY KIND OR NATURE TO OWNER OR ANY PARTY
CLAIMING THROUGH OWNER, WHETHER BASED IN CONTRACT, NEGLIGENCE, TORT OR STRICT PRODUCTS LIABILITY OR ARISING FROM
ANY CAUSE WHATSOEVER. Some states do not allow the exclusion of consequential damages, so the above exclusion may not apply to you.
This warranty gives you specific rights; you may also have others that vary from state to state.
INSTRUCCIONES DE SEGURIDAD IMPORTANTES
¡GUARDE ESTAS INSTRUCCIONES!
Cuando se utilizan aparatos eléctricos, siempre deben seguirse precauciones básicas, incluidas las siguientes:
1. GUARDE ESTAS INSTRUCCIONES. Este manual contiene instrucciones importantes sobre la seguridad y el funcionamiento del
cargador de batería Modelo CH90002.
2. Antes de utilizar un cargador de batería, lea todas las instrucciones e indicaciones de advertencia del cargador de batería, la batería
y el producto en el que use la batería.
3. PRECAUCIÓN: Para reducir el riesgo de lesiones, cargue solamente baterías recargables del tipo de ión de litio. Las baterías de otro
tipo podrían estallar y provocar lesiones personales y daños.
ADVERTENCIA: PARA DISMINUIR EL RIESGO DE INCENDIO, DESCARGA ELÉCTRICA
O LESIONES:
• Este producto solo tiene como fin su uso comercial.
• No utilice o almacene la unidad en exteriores o en superficies mojadas, ni cargue la batería en dichas condiciones. Evite que la unidad
se moje.
• Evite que se la utilice como un juguete. La unidad no tiene como fin el uso por parte de niños de 12 años o menos. Cuando se la utilice
cerca de niños, será necesario hacerlo bajo una estricta supervisión. Para evitar lesiones o daños, mantenga a los niños alejados del
producto y no permita que introduzcan los dedos ni objetos en ninguna de las aberturas del producto.
• Utilícela únicamente según el uso descripto en este manual. Utilice solamente los accesorios y productos recomendados por el
fabricante.
• No utilice el cargador si el cable o el enchufe se encuentran dañados. Si el aparato o el cargador no funcionan como deben; si se han
caído, han sido dañados, dejados a la intemperie o sumergidos en agua, llévelos a un Centro Técnico antes de continuar usándolos.
• No extraiga ni transporte el cargador tomándolo por el cable; no tire del cable, no cierre una puerta con él ni lo enrosque alrededor de
bordes o esquinas filosas. No apoye el producto sobre el cable. No pase el aparato por encima del cable. Mantenga el cable lejos de
las superficies calientes.
• No apoye el producto sobre el cable. No pase el aparato por encima del cable. Mantenga el cable lejos de las superficies calientes.
• No desenchufe el cargador tirando del cable. Para desenchufarlo, agarre el enchufe, no el cable.
• No manipule el cargador (incluido el enchufe y los terminales, o el aparato) ni el aparato con las manos mojadas.
• No incinere el cargador, la batería ni el aparato, aun si estuvieran muy dañados. Las baterías pueden explotar y provocar un incendio.
• Este producto incluye baterías recargables de iones de litio. No exponga las baterías a altas temperaturas, ya que pueden prenderse
fuego o explotar.
• No aplaste ni incinere la batería, ni la someta a acciones similares.
• No deseche la batería en un incinerador ni en un compactador de desechos. Consulte la sección sobre desecho de la batería para
obtener instrucciones.
• No intente desarmar la batería.
• Desenchufe el cargador del tomacorriente antes de llevar a cabo una rutina de limpieza o mantenimiento en la unidad.
• En condiciones extremas, pueden producirse pérdidas en las celdas de la batería. Si la piel entrara en contacto con el líquido, lávese
rápidamente con jabón y agua. Si el líquido le entrara en los ojos, no los frote. Enjuáguelos de inmediato con agua limpia, en forma
continua durante, al menos, 15 minutos. Consulte a un médico de inmediato.
• Para recargar la unidad, utilice únicamente el cargador (N.º de pieza Hoover CH90002) provisto por Hoover
• Utilice únicamente la batería (N.º de pieza Hoover CH90040) provista por Hoover
o daños físicos graves.
• No toque el bloque de batería ni los terminales del cargador, ni inserte objetos en ellos.
• El cargador es para uso en interiores solamente. Siempre asegúrese de guardar la batería y el cargador en un lugar seco.
• No intente cortocircuitar la batería ni los terminales del cargador.
• Este producto incluye baterías recargables de iones de litio. No exponga las baterías a altas temperaturas, ya que pueden prenderse
fuego o explotar.
• Mantenga el cargador alejado de las zonas donde pueda haber aceite.
PRECAUCIÓN: PARA DISMINUIR EL RIESGO DE DAÑOS:
• Almacénelo apropiadamente en interiores, en un lugar seco. No exponga el cargador ni las baterías a temperaturas muy frías.
ADVERTENCIA: ESTE PRODUCTO CONTIENE QUÍMICOS RECONOCIDOS POR EL ESTADO
DE CALIFORNIA COMO CAUSANTES DE CÁNCER, DEFECTOS DE NACIMIENTO U OTROS DAÑOS
REPRODUCTIVOS. LÁVESE LAS MANOS LUEGO DE UTILIZARLO.
ADVERTENCIA: PARA REDUCIR EL RIESGO DE DESCARGA ELÉCTRICA, EL CARGADOR TIENE
UN ENCHUFE POLARIZADO (UNA CLAVIJA ES MÁS ANCHA QUE LA OTRA). ESTE ENCHUFE CABE
EN UN TOMACORRIENTE POLARIZADO DE UNA SOLA MANERA. SI NO ENCAJA POR COMPLETO EN
EL TOMACORRIENTE, INVIERTA EL ENCHUFE. SI AÚN NO ENCAJA, CONTACTE A UN ELECTRICISTA
CUALIFICADO PARA QUE INSTALE EL TOMACORRIENTE CORRESPONDIENTE. NO REALICE NINGÚN
TIPO DE MODIFICACIÓN EN EL ENCHUFE.
CARACTÉRISTIQUES
1
2
4
3
CHARGE DE LA PILE DE 40 V M-PWR
REMARQUE : La charge des piles livrées est minime afin d'éviter toute possibilité de problèmes. Vous devez charger la pile avant la
première utilisation.
Le chargeur ne charge qu'une pile à la fois. Lorsque deux piles sont installées sur le chargeur, la pile ayant une charge plus élevée sera
chargée en premier. Ceci permet de charger complètement la pile en moins de temps.
Insérer la pile sur L'indicateur DEL de
le chargeur pour niveau de charge
commencer la charge, passera au vert dès que
Poussez la pile vers la charge est terminée.
l'arrière jusqu'à ce
Si le témoin du chargeur
qu'elle s'enclenche et
clignote en rouge, une
que l'indicateur DEL
erreur s'est produite.
de niveau de charge
Retirez la pile et
s'allume.
remplacez-la.
© 2016 TECHTRONIC FLOOR CARE TECHNOLOGY LIMITED. ALL RIGHTS RESERVED. #961152017
Commercial charger and battery
®
40V products purchased in the United States, U.S. Military Exchanges and Canada.
Commercial Authorized Warranty Service Dealer along with proof of
®
®
Commercial, owner's acts or omissions, use outside the
®
® Commercial Sales and
Commercial, 1-800-944-9200,
®
® .
. Otras baterías pueden explotar y causar lesiones
®
Batterie
1. Indicateur DEL de niveau de
charge
2. Bouton de vérification de l'état
de charge
5
3. Bouton de déclenchement
4. Bornes de branchement
Chargeur
5. Indicateur DEL
MC
Niveau de charge
de 66 à 100 %
Niveau de charge
de 33 à 66 %
Niveau de charge
de 10 à 33 %
Niveau de charge
de 0 à 10 %
Pendant la charge, les
témoins DEL allumés
de la pile indiqueront le
niveau de charge.
PLAGE DE TEMPÉRATURE POUR UNE
CHARGE À TEMPÉRATURE AMBIANTE :
5 °C – 50 °C (41 °F – 122 °F)
Commercial authorized
® COMMERCIAL BE
Pour retirer la pile,
appuyez sur le bouton de
déclenchement et glissez
la pile tout vers l'avant
tout en maintenant la
base du chargeur en
place.
ID117384
•
